385W High Efficiency Lg Neon® R Prime Solar Panel For Home With 60 Cells (6 X 10), Module Efficiency: 21.2%, Connector Type: Mc4
SKU: LG385Q1KA6
Where Can I See This Product in Store?
This product is not on display in our showrooms.
Estimated Delivery Price
Enter your zip code to get a delivery estimate.
Description
- Excellent performance, even on a cloudy day
- High Power Output
- Durable design
- Streamlined, Uniform Roof Aesthetic
- 25 Year Limited Warranty
Rebates
view available rebates
385W High Efficiency Lg Neon® R Prime Solar Panel For Home With 60 Cells (6 X 10), Module Efficiency: 21.2%, Connector Type: Mc4
Misc Collection
Specifications
Specifications
Features
Excellent performance, even on a cloudy day, High Power Output, Durable design, Streamlined, Uniform Roof Aesthetic, 25 Year Limited Warranty
- Excellent performance, even on a cloudy day
- High Power Output
- Durable design
- Streamlined, Uniform Roof Aesthetic
- 25 Year Limited Warranty
General Data
Cell Properties (Material/Type)
Monocrystalline/N-type
Cell Properties (Material/Type)
- Monocrystalline/N-type
Cell Maker
LG
Cell Maker
- LG
Cell Configuration
60 Cells (6 x 10)
Cell Configuration
- 60 Cells (6 x 10)
Number of Busbars
TBD
Number of Busbars
- TBD
Module Dimensions (L x W x H)
1,740mm x 1,042mm x 40mm
Module Dimensions (L x W x H)
- 1,740mm x 1,042mm x 40mm
Weight
18.5kg
Weight
- 18.5kg
Glass (Thickness/Material)
2.8mm/Tempered Glass with AR Coating
Glass (Thickness/Material)
- 2.8mm/Tempered Glass with AR Coating
Backsheet (Color)
Black
Backsheet (Color)
- Black
Frame (Material)
Anodized Aluminium
Frame (Material)
- Anodized Aluminium
Junction Box (Protection Degree)
IP68 with 3 Bypass Diodes
Junction Box (Protection Degree)
- IP68 with 3 Bypass Diodes
Cables (Length)
1,250mm x 2EA
Cables (Length)
- 1,250mm x 2EA
Connector (Type/Maker)
MC 4/MC
Connector (Type/Maker)
- MC 4/MC
Certifications and Warranty
Certifications
IEC 61215-1/-1-1/-2:2016, IEC 61730-1/2:2016, UL 61730, ISO 9001, ISO 14001, ISO 50001, OHSAS 18001
Certifications
- IEC 61215-1/-1-1/-2:2016, IEC 61730-1/2:2016, UL 61730, ISO 9001, ISO 14001, ISO 50001, OHSAS 18001
Salt Mist Corrosion Test
IEC 61701:2012 Severity 6
Salt Mist Corrosion Test
- IEC 61701:2012 Severity 6
Ammonia Corrosion Test
IEC 62716:2013
Ammonia Corrosion Test
- IEC 62716:2013
Module Fire Performance
Type 2
Module Fire Performance
- Type 2
Fire Rating
Class C (UL 790)
Fire Rating
- Class C (UL 790)
Product Warranty
25 Year Limited
Product Warranty
- 25 Year Limited
Output Warranty of Pmax
Linear Warranty*
Output Warranty of Pmax
- Linear Warranty*
*
Improved: 1st year 98.5%, from 2-24th year: -0.25%/year down, 92.5% at year 25
*
- Improved: 1st year 98.5%, from 2-24th year: -0.25%/year down, 92.5% at year 25
**
Full warranty details can be found below.
**
- Full warranty details can be found below.
Temperature Characteristics
NMOT* [°C]
44 3
NMOT* [°C]
- 44 3
Pmax [%/°C]
-0.29
Pmax [%/°C]
- -0.29
Voc [%/°C]
-0.24
Voc [%/°C]
- -0.24
Isc [%/°C]
0.04
Isc [%/°C]
- 0.04
*
NMOT (Nominal Module Operating Temperature): Irradiance 800 W/m2, Ambient temperature 20 °C, Wind speed 1 m/s, Spectrum AM 1.5
*
- NMOT (Nominal Module Operating Temperature): Irradiance 800 W/m2, Ambient temperature 20 °C, Wind speed 1 m/s, Spectrum AM 1.5
Electrical Properties (NMOT)
Model
TBD
Model
- TBD
Maximum Power (Pmax) [W]
292
Maximum Power (Pmax) [W]
- 292
MPP Voltage (Vmpp) [V]
35.3
MPP Voltage (Vmpp) [V]
- 35.3
MPP Current (Impp) [A]
8.26
MPP Current (Impp) [A]
- 8.26
Open Circuit Voltage (Voc) [V]
41.7
Open Circuit Voltage (Voc) [V]
- 41.7
Short Circuit Current (Isc) [A]
8.76
Short Circuit Current (Isc) [A]
- 8.76
Electrical Properties (STC*)
Model
TBD
Model
- TBD
Maximum Power (Pmax) [W]
385
Maximum Power (Pmax) [W]
- 385
MPP Voltage (Vmpp) [V]
37.4
MPP Voltage (Vmpp) [V]
- 37.4
MPP Current (Impp) [A]
10.30
MPP Current (Impp) [A]
- 10.30
Open Circuit Voltage (Voc) [V]
43.7
Open Circuit Voltage (Voc) [V]
- 43.7
Short Circuit Current (Isc) [A]
10.86
Short Circuit Current (Isc) [A]
- 10.86
Module Efficiency [%]
21.2
Module Efficiency [%]
- 21.2
Power Tolerance [%]
0 ~ +3
Power Tolerance [%]
- 0 ~ +3
*
STC (Standard Test Condition): Irradiance 1000 W/m , cell temperature 25 °C, AM 1.5, Measure Tolerance of Pmax: +/- 3%.
*
- STC (Standard Test Condition): Irradiance 1000 W/m , cell temperature 25 °C, AM 1.5, Measure Tolerance of Pmax: +/- 3%.
Operating Conditions
Operating Temperature [°C]
-40 ~+85
Operating Temperature [°C]
- -40 ~+85
Maximum System Voltage [V]
1,000
Maximum System Voltage [V]
- 1,000
Maximum Series Fuse Rating [A]
20
Maximum Series Fuse Rating [A]
- 20
Mechanical Test Load (Front) [Pa/psf]
5,400/113
Mechanical Test Load (Front) [Pa/psf]
- 5,400/113
Mechanical Test Load (Rear) [Pa/psf]
4,000/84
Mechanical Test Load (Rear) [Pa/psf]
- 4,000/84
*
Test Load = Design x Safety Factor (1.5)
*
- Test Load = Design x Safety Factor (1.5)
Packaging Configuration
Number of Modules per Pallet [EA]
25
Number of Modules per Pallet [EA]
- 25
Number of Modules per 40ft HQ Container [EA]
650
Number of Modules per 40ft HQ Container [EA]
- 650
Number of Modules per 53' Container [EA]
850
Number of Modules per 53' Container [EA]
- 850
Packaging Box Dimensions (L x W x H) [mm]
1,790 x 1,120 x 1,227
Packaging Box Dimensions (L x W x H) [mm]
- 1,790 x 1,120 x 1,227
Packaging Box Dimensions (L x W x H) [in]
TBD
Packaging Box Dimensions (L x W x H) [in]
- TBD
Packaging Box Gross Weight [kg]
498
Packaging Box Gross Weight [kg]
- 498
Packaging Box Gross Weight [lb]
TBD
Packaging Box Gross Weight [lb]
- TBD
Item & Dimensions
Manufacturer
LG Appliances
Manufacturer
- LG Appliances
The Misc 385W High Efficiency Lg Neon® R Prime Solar Panel For Home With 60 Cells (6 X 10), Module Efficiency: 21.2%, Connector Type: Mc4, made by LG Appliances,
