Gscd 10.41Mm Ultra Light Series Outdoor Led With Two Cabinet Options, 5,000 Nits Brightness, Ip65 Rated, & 90° Corner Option
SKU: GSCD100GN
Where Can I See This Product in Store?
This product is not on display in our showrooms.
Estimated Delivery Price
Enter your zip code to get a delivery estimate.
Description
Easy Maintenance
Power and control units attached to the cabinets can be removed, making it easy to fix problems that may arise.
Front or Rear Serviceability
The product offers either front access or rear access, allowing customers to choose installation options according to their environment and minimizes limitations in installation and maintenance.
Lightweight Design
The cabinets of the GSCD series are much lighter than other outdoor LED displays weighing 46.7 lbs. & 41.88 lbs. This reduces the load on the building when a large LED screen is installed on it.
*Image for illustration purposes only.
90° Corner Design Available
If you add a 90° corner option*, the GSCD series can deliver virtually flawless content even when installed on the corners.
IP Rated Weatherproof Design
The front and back of the cabinet are IP65 certified, allowing stable operation during bad weather and harmful outdoor environments.
Power and control units attached to the cabinets can be removed, making it easy to fix problems that may arise.
Front or Rear Serviceability
The product offers either front access or rear access, allowing customers to choose installation options according to their environment and minimizes limitations in installation and maintenance.
Lightweight Design
The cabinets of the GSCD series are much lighter than other outdoor LED displays weighing 46.7 lbs. & 41.88 lbs. This reduces the load on the building when a large LED screen is installed on it.
*Image for illustration purposes only.
90° Corner Design Available
If you add a 90° corner option*, the GSCD series can deliver virtually flawless content even when installed on the corners.
IP Rated Weatherproof Design
The front and back of the cabinet are IP65 certified, allowing stable operation during bad weather and harmful outdoor environments.
- IP65 Weatherproof Design
- Brightness: 5,000nits
- Lightweight Design
- 90 Corner Option Available
- Pixel Pitch: 10.41mm
- Two Cabinet options
Rebates
view available rebates
Gscd 10.41Mm Ultra Light Series Outdoor Led With Two Cabinet Options, 5,000 Nits Brightness, Ip65 Rated, & 90° Corner Option
Misc Collection
Specifications
Specifications
Features
IP65 Weatherproof Design, Brightness: 5,000nits, Lightweight Design, 90 Corner Option Available, Pixel Pitch: 10.41mm, Two Cabinet options
- IP65 Weatherproof Design
- Brightness: 5,000nits
- Lightweight Design
- 90 Corner Option Available
- Pixel Pitch: 10.41mm
- Two Cabinet options
PHYSICAL PARAMETERS
Pixel Configuration
3 in 1 SMD
Pixel Configuration
- 3 in 1 SMD
Pixel Pitch
10.41 mm
Pixel Pitch
- 10.41 mm
Module Resolution (W x H)
48 x 24
Module Resolution (W x H)
- 48 x 24
Module Dimensions (W x H)
19.7 x 9.8 in / 500 x 250 mm
Module Dimensions (W x H)
- 19.7 x 9.8 in / 500 x 250 mm
Weight per Module
2.9 lbs / 1.3 kg
Weight per Module
- 2.9 lbs / 1.3 kg
LED Package Manufacturer
Nationstar
LED Package Manufacturer
- Nationstar
No. of Modules per Unit Case (W x H)
2 x 4
No. of Modules per Unit Case (W x H)
- 2 x 4
Unit Case Resolution (W x H, pixels)
96 x 96
Unit Case Resolution (W x H, pixels)
- 96 x 96
Unit Case Dimensions (W x H x D)
39.4 39.4 x 3.4 in 1000 x 1000 x 85.1mm
Unit Case Dimensions (W x H x D)
- 39.4 39.4 x 3.4 in 1000 x 1000 x 85.1mm
Unit Case Surface Area
10.8 m2 / 1 m2
Unit Case Surface Area
- 10.8 m2 / 1 m2
Weight per Unit Case
41.9 lbs / 19 kg
Weight per Unit Case
- 41.9 lbs / 19 kg
Weight per Square Meter
3.9 lb/ft2 / 19 kg/m2
Weight per Square Meter
- 3.9 lb/ft2 / 19 kg/m2
Physical Pixel Density (pixels/m )
857 pixels/ft2 / 9,216 pixels/m
Physical Pixel Density (pixels/m )
- 857 pixels/ft2 / 9,216 pixels/m
Flatness of Unit Case (mm)
0.5
Flatness of Unit Case (mm)
- 0.5
Unit Case Material
Aluminum Profiles
Unit Case Material
- Aluminum Profiles
Service Access
Front or Rear (select one only)
Service Access
- Front or Rear (select one only)
OPTICAL SPECIFICATIONS
Brightness
5,000nits
Brightness
- 5,000nits
Color Temperature
3,500 to 9,000 K
Color Temperature
- 3,500 to 9,000 K
Visual Viewing Angle (Horizontal)
160°
Visual Viewing Angle (Horizontal)
- 160°
Visual Viewing Angle (Vertical)
136°
Visual Viewing Angle (Vertical)
- 136°
Brightness Uniformity
97%
Brightness Uniformity
- 97%
Color Uniformity
0.003CxCy
Color Uniformity
- 0.003CxCy
Contrast Ratio
10,000
Contrast Ratio
- 10,000
Processing Depth
14 bit
Processing Depth
- 14 bit
ELECTRICAL SPECIFICATIONS
Max Power Consumption per Unit
650 W, 2218 BTU
Max Power Consumption per Unit
- 650 W
- 2218 BTU
Average Power Consumption per Unit
216 W, 737 BTU
Average Power Consumption per Unit
- 216 W
- 737 BTU
Max Power Consumption per Unit Area
650 W/m, 2,218 BTU/m
Max Power Consumption per Unit Area
- 650 W/m
- 2,218 BTU/m
Power Supply
100 to 240 Vac
Power Supply
- 100 to 240 Vac
Frame Rate
50 / 60 Hz
Frame Rate
- 50 / 60 Hz
Refresh Rate
3847 Hz
Refresh Rate
- 3847 Hz
OPERATION SPECIFICATIONS
LED Lifetime (Half brightness)
100,000 hrs
LED Lifetime (Half brightness)
- 100,000 hrs
Operating Temperature
-4°F to 122°F/-20°C to +50°C
Operating Temperature
- -4°F to 122°F/-20°C to +50°C
Operating Humidity
10-99% RH
Operating Humidity
- 10-99% RH
IP Rating Front
IP65
IP Rating Front
- IP65
IP Rating Rear
IP65
IP Rating Rear
- IP65
CERTIFICATIONS
FCC (Regulatory)
Yes
FCC (Regulatory)
- Yes
CE (Regulatory)
Yes
CE (Regulatory)
- Yes
ETL (Safety)
Yes
ETL (Safety)
- Yes
RoHS (Environmental)
Yes
RoHS (Environmental)
- Yes
CONTROLLER
Controller
LCIN006
Controller
- LCIN006
90 degree corner cut
Yes
90 degree corner cut
- Yes
Item & Dimensions
Manufacturer
LG Appliances
Manufacturer
- LG Appliances
