.94Mm Magnit Microled With Remote Power, Power Redundancy, Ip50 Front & Ip20 Rear, & Lg Software Compatible
SKU: LSAQ009
Where Can I See This Product in Store?
This product is not on display in our showrooms.
Estimated Delivery Price
Enter your zip code to get a delivery estimate.
Description
Remote Power and Power Redundancy
LSAQ's Remote Power Supply Unit (PSU) is designed to be installed separately from the screen, rather than inside the cabinet. This unique design allows for hot swapping, which means that failed Power Module can be replaced without disrupting the operation of the screen. This results in minimal downtime and maximizes efficiency, making it a great choice for businesses and organizations that require uninterrupted performance.
*Image simulation for illustration purposes only.
Enhanced Uniformity with LG Surface Treatment (LST) Technology
LG MAGNIT's innovative Chip Transfer and Surface Treatment Technology enhances white uniformity and reduces color distortion from virtually any angle, delivering a wide-angle viewing experiences. This technology ensures remarkable color uniformity, resulting in stunning image quality.
Achieving True Black with Direct Chip Mounting
LG MAGNIT's advanced and precise method for direct bonding micro-sized chips onto circuit boards combined with the black coating technology, creates a stunning black expression that stands out compared to SMD-type LED displays. This makes it the ideal choice for displaying content that requires deep black color, ensuring that every image is rich, vibrant, and true to life.
*Based on LG's conventional LED Signage
Colors as Intended
The narrow wavelength of the LED chip allows uniform color across the screen. And with the support of Gamut Transfer technology, color is displayed close to the original color. This can be essential for some businesses.
Ai-powered Viewing Experience with Alpha 7 Processor
LG MAGNIT features an advanced AI-powered Alpha 7 Intelligent Processor that optimizes clarity and sharpness to deliver an outstanding viewing experience. Its advanced AI technology enables the processor to recognize and analyze content, tailoring the display settings for each individual scene to create a highly realistic and immersive image possible.
Sleek Look with Smooth Surface
The screen surface of LG MAGNIT is very smooth just as LCD, making it look nice even when the screen is off. The screen also feels soft to the touch. If fingerprints are on the surface, they can be simply removed by wiping it a soft cloth without the need for any chemicals.
IP50 and IP20 Sturdy Design
Through several layers of coated film, LG MAGNIT can protect its LED chips from risks caused by water drops, dust, static electricity or physical impacts. Considering that it is usually installed in public places where many people come and go, its stability is vitally important to minimize unforeseen accidents. The front is IP50 rated, while the back is IP20 rated.
*Image simulation for illustration purposes only.
Compatibility with LG Software Solutions
When connected with LG's CSAB system controller, the LSAQ series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.
LSAQ's Remote Power Supply Unit (PSU) is designed to be installed separately from the screen, rather than inside the cabinet. This unique design allows for hot swapping, which means that failed Power Module can be replaced without disrupting the operation of the screen. This results in minimal downtime and maximizes efficiency, making it a great choice for businesses and organizations that require uninterrupted performance.
*Image simulation for illustration purposes only.
Enhanced Uniformity with LG Surface Treatment (LST) Technology
LG MAGNIT's innovative Chip Transfer and Surface Treatment Technology enhances white uniformity and reduces color distortion from virtually any angle, delivering a wide-angle viewing experiences. This technology ensures remarkable color uniformity, resulting in stunning image quality.
Achieving True Black with Direct Chip Mounting
LG MAGNIT's advanced and precise method for direct bonding micro-sized chips onto circuit boards combined with the black coating technology, creates a stunning black expression that stands out compared to SMD-type LED displays. This makes it the ideal choice for displaying content that requires deep black color, ensuring that every image is rich, vibrant, and true to life.
*Based on LG's conventional LED Signage
Colors as Intended
The narrow wavelength of the LED chip allows uniform color across the screen. And with the support of Gamut Transfer technology, color is displayed close to the original color. This can be essential for some businesses.
Ai-powered Viewing Experience with Alpha 7 Processor
LG MAGNIT features an advanced AI-powered Alpha 7 Intelligent Processor that optimizes clarity and sharpness to deliver an outstanding viewing experience. Its advanced AI technology enables the processor to recognize and analyze content, tailoring the display settings for each individual scene to create a highly realistic and immersive image possible.
Sleek Look with Smooth Surface
The screen surface of LG MAGNIT is very smooth just as LCD, making it look nice even when the screen is off. The screen also feels soft to the touch. If fingerprints are on the surface, they can be simply removed by wiping it a soft cloth without the need for any chemicals.
IP50 and IP20 Sturdy Design
Through several layers of coated film, LG MAGNIT can protect its LED chips from risks caused by water drops, dust, static electricity or physical impacts. Considering that it is usually installed in public places where many people come and go, its stability is vitally important to minimize unforeseen accidents. The front is IP50 rated, while the back is IP20 rated.
*Image simulation for illustration purposes only.
Compatibility with LG Software Solutions
When connected with LG's CSAB system controller, the LSAQ series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.
- IP50 Rating Front and IP20 Rating Rear
- Front & Rear Service Access for Easy Install & Maintance
- Experience True Black and Stunning Colors (HDR10, HDR10 Pro)
- Compatible with CSAB-00915D Controller
- .94 mm Pixel Pitch with 160° x 160° Viewing Angle
- Lifetime up to 100,000 hours
Rebates
view available rebates
Specifications
Specifications
Features
IP50 Rating Front and IP20 Rating Rear, Front & Rear Service Access for Easy Install & Maintance, Experience True Black and Stunning Colors (HDR10, HDR10 Pro), Compatible with CSAB-00915D Controller, .94 mm Pixel Pitch with 160° x 160° Viewing Angle, Lifetime up to 100,000 hours
- IP50 Rating Front and IP20 Rating Rear
- Front & Rear Service Access for Easy Install & Maintance
- Experience True Black and Stunning Colors (HDR10, HDR10 Pro)
- Compatible with CSAB-00915D Controller
- .94 mm Pixel Pitch with 160° x 160° Viewing Angle
- Lifetime up to 100,000 hours
PHYSICAL PARAMETERS
Pixel Configuration
Micro
Pixel Configuration
- Micro
Pixel Pitch (mm)
0.9375
Pixel Pitch (mm)
- 0.9375
Module Resolution (W x H)
320 x 120
Module Resolution (W x H)
- 320 x 120
Module Dimensions (W x H, mm)
300 x 112.5
Module Dimensions (W x H, mm)
- 300 x 112.5
Weight per Module (Ibs. / kg)
0.42 / 0.19
Weight per Module (Ibs. / kg)
- 0.42 / 0.19
No. of Modules per Cabinet (W x H)
2 x 3
No. of Modules per Cabinet (W x H)
- 2 x 3
Cabinet Resolution (W x H)
640 x 360
Cabinet Resolution (W x H)
- 640 x 360
Cabinet Dimensions (W x H x D, in. / mm)
23.6 x 13.3 x 1.8 / 600 x 337.5 x 44.9
Cabinet Dimensions (W x H x D, in. / mm)
- 23.6 x 13.3 x 1.8 / 600 x 337.5 x 44.9
Cabinet Surface Area (ft / m )
2.2 / 0.203
Cabinet Surface Area (ft / m )
- 2.2 / 0.203
Weight per Cabinet (Ibs. / kg)
14.1 / 6.4
Weight per Cabinet (Ibs. / kg)
- 14.1 / 6.4
Weight per Square Meter (Ibs./ft / kg/m )
6.5 / 31.6
Weight per Square Meter (Ibs./ft / kg/m )
- 6.5 / 31.6
Physical Pixel Density (pixels/m )
1,137,778
Physical Pixel Density (pixels/m )
- 1,137,778
Flatness of Cabinet (mm)
0.5
Flatness of Cabinet (mm)
- 0.5
Cabinet Material
Extrusion Aluminum
Cabinet Material
- Extrusion Aluminum
Service Access
Front and Rear
Service Access
- Front and Rear
OPTICAL SPECIFICATIONS
Max. Brightness (After Calibration, nits)
600 (typ) / 1,200 (peak)
Max. Brightness (After Calibration, nits)
- 600 (typ) / 1,200 (peak)
Color Temperature (K)
3,200-9,300 / (Default) 7,300
Color Temperature (K)
- 3,200-9,300 / (Default) 7,300
Visual Viewing Angle (H x V)
160° x 160°
Visual Viewing Angle (H x V)
- 160° x 160°
Brightness Uniformity
95%
Brightness Uniformity
- 95%
Color Uniformity
0.02 Cx, Cy
Color Uniformity
- 0.02 Cx, Cy
Contrast Ratio
100,000 : 1 @ 10lux
Contrast Ratio
- 100,000 : 1 @ 10lux
Processing Depth (bit)
20 (HDR10, HDR10 Pro)
Processing Depth (bit)
- 20 (HDR10, HDR10 Pro)
ELECTRICAL SPECIFICATIONS
Power Consumption (W/Cabinet, Max.)
67
Power Consumption (W/Cabinet, Max.)
- 67
Power Consumption (W/Cabinet, Avg.)
40
Power Consumption (W/Cabinet, Avg.)
- 40
Power Consumption (W/m , Max.)
331
Power Consumption (W/m , Max.)
- 331
Heat Dissipation (BTU/h/Screen, Max.)
229
Heat Dissipation (BTU/h/Screen, Max.)
- 229
Heat Dissipation (BTU/h/Screen, Avg.)
137
Heat Dissipation (BTU/h/Screen, Avg.)
- 137
Heat Dissipation (BTU/h/m , Max.)
1,132
Heat Dissipation (BTU/h/m , Max.)
- 1,132
Power Supply (Vac)
48 Vdc
Power Supply (Vac)
- 48 Vdc
Frame Rate (Hz)
50 / 60
Frame Rate (Hz)
- 50 / 60
Refresh Rate (Hz)
3,840
Refresh Rate (Hz)
- 3,840
OPERATION SPECIFICATIONS
LED Lifetime (Half brightness)
Up to 100,00 hours
LED Lifetime (Half brightness)
- Up to 100,00 hours
Operating Temperature (°F / °C)
32 to 104 / 0 to 40
Operating Temperature (°F / °C)
- 32 to 104 / 0 to 40
Operating Humidity
10-80%RH
Operating Humidity
- 10-80%RH
IP Rating Front / Rear
IP50 / IP20
IP Rating Front / Rear
- IP50 / IP20
SPECIFICATIONS
Warranty
3 Year Limited
Warranty
- 3 Year Limited
Certification
Safety 60950-1, EMC Class B, BS476 Part7 Class2Y
Certification
- Safety 60950-1, EMC Class B, BS476 Part7 Class2Y
Environment
RoHS
Environment
- RoHS
Controller
CSAB-00915D
Controller
- CSAB-00915D
90 Degree Corner Cut
No
90 Degree Corner Cut
- No
