55" Ips Uhd Multi Touch Screen Digital Display With Webos 4.1 Smart Signage Platform, Anti-Shatter Glass, Conformal Coating & Embedded Group Manager
SKU: 55TC3CGH
Where Can I See This Product in Store?
moreThis product is not on display in our showrooms.
Estimated Delivery Price
Enter your zip code to get a delivery estimate.
Ask a Question
lessDisclaimer
Description
morePrecise Touch Response
The screen accurately recognizes extremely small touch points and instantly shows a response. This means that SIs can compose GUI icons in a variety of sizes on the 55TC3CG-H and users can fully enjoy their touch experience with no lagging.
Multi Touch with No Dead Zones
Capable of recognizing up to 40 point-touches at once, the screen provides multiple users a smooth and natural sense of touch. Unlike infrared touch screens, the 55TC3CG-H accurately detects touch points even at the corners or edges of the display. This allows a variety of touch-based customer services to be provided throughout the entire screen.
Fewer Scratches & Shatter Proof
Touch screens in public spaces can be scratched in heavy use or even abuse situations. The 55TC3CG-H has an advanced tempered screen coating to minimize scratches. In addition, its anti-shatter glass is designed to minimize harm to the user, even in the event the product being subject to abuse.
Conformal Coating
The product can be often unavoidably exposed to dust and water during maintenance. Conformal coating on the circuit board virtually eliminates such circumstances by protecting it against dust, iron powder, humidity, etc.
Embedded Group Manager
The embedded content management system allows you to edit and play content, schedule a playlist and even group and control signage via remote control, without need for a separate PC. This makes content management much easier and user-friendly.
Multi Screen Mode
PBP (Picture-By-Picture) and PIP (Picture-In-Picture) enables up to two divided split screens in landscape or portrait display format enabling users to more flexibly allocate space for each content source.
Various Sensor Applications
LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc. via USB plug-in. With webOS smart signage, there's no need to purchase additional software or media players.
OPS Player Connectivity
The 55TC3CG-H provides an Open Pluggable Specification (OPS) Kit to connect a third-party OPS player. Users have the flexibility to choose any media player as long as it complies with the OPS.
LG Recognized as MSAP Leader
LG's environmental practices have earned us the title of Leader in the MindClick Sustainability Assessment Program 22-23. MSAP Ratings recognize environmental and social leadership by acknowledging manufacturers who promote sustainability and sustainable practices. LG has earned the Leader status in the categories of Cruise TVs, Healthcare TVs, Digital Signage, Small Monitors, and Hospitality: H Models.
Engage your Audience
The 55TC3CG-H offers high touch performance and great color with vivid details that can seen at virtually any angle.
*Image for illustration purposes only.
The screen accurately recognizes extremely small touch points and instantly shows a response. This means that SIs can compose GUI icons in a variety of sizes on the 55TC3CG-H and users can fully enjoy their touch experience with no lagging.
Multi Touch with No Dead Zones
Capable of recognizing up to 40 point-touches at once, the screen provides multiple users a smooth and natural sense of touch. Unlike infrared touch screens, the 55TC3CG-H accurately detects touch points even at the corners or edges of the display. This allows a variety of touch-based customer services to be provided throughout the entire screen.
Fewer Scratches & Shatter Proof
Touch screens in public spaces can be scratched in heavy use or even abuse situations. The 55TC3CG-H has an advanced tempered screen coating to minimize scratches. In addition, its anti-shatter glass is designed to minimize harm to the user, even in the event the product being subject to abuse.
Conformal Coating
The product can be often unavoidably exposed to dust and water during maintenance. Conformal coating on the circuit board virtually eliminates such circumstances by protecting it against dust, iron powder, humidity, etc.
Embedded Group Manager
The embedded content management system allows you to edit and play content, schedule a playlist and even group and control signage via remote control, without need for a separate PC. This makes content management much easier and user-friendly.
Multi Screen Mode
PBP (Picture-By-Picture) and PIP (Picture-In-Picture) enables up to two divided split screens in landscape or portrait display format enabling users to more flexibly allocate space for each content source.
Various Sensor Applications
LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc. via USB plug-in. With webOS smart signage, there's no need to purchase additional software or media players.
OPS Player Connectivity
The 55TC3CG-H provides an Open Pluggable Specification (OPS) Kit to connect a third-party OPS player. Users have the flexibility to choose any media player as long as it complies with the OPS.
LG Recognized as MSAP Leader
LG's environmental practices have earned us the title of Leader in the MindClick Sustainability Assessment Program 22-23. MSAP Ratings recognize environmental and social leadership by acknowledging manufacturers who promote sustainability and sustainable practices. LG has earned the Leader status in the categories of Cruise TVs, Healthcare TVs, Digital Signage, Small Monitors, and Hospitality: H Models.
Engage your Audience
The 55TC3CG-H offers high touch performance and great color with vivid details that can seen at virtually any angle.
*Image for illustration purposes only.
- Anti-shatter Glass & Conformal Coating
- Multi Touch Screen (Up to 40 points)
- webOS 4.1 Smart Signage Platform
- SuperSign CMS, Control/Control+
- IPS Display with wide viewing angles
Quick Setup Guide English,Spanish 5,991K 05/22/2024
View PDF for more information
Rebates
view available rebates
Specifications
Specifications
Features
Anti-shatter Glass & Conformal Coating, Multi Touch Screen (Up to 40 points), webOS 4.1 Smart Signage Platform, SuperSign CMS, Control/Control+, IPS Display with wide viewing angles
- Anti-shatter Glass & Conformal Coating
- Multi Touch Screen (Up to 40 points)
- webOS 4.1 Smart Signage Platform
- SuperSign CMS, Control/Control+
- IPS Display with wide viewing angles
DISPLAY
Screen Size
55"
Screen Size
- 55"
Panel Technology
IPS
Panel Technology
- IPS
Back Light Type
Edge
Back Light Type
- Edge
Aspect Ratio
16:9
Aspect Ratio
- 16:9
Native Resolution
3840 x 2160 (UHD)
Native Resolution
- 3840 x 2160 (UHD)
Refresh Rate
60Hz
Refresh Rate
- 60Hz
Brightness
350nits (Typ.)
Brightness
- 350nits (Typ.)
Contrast Ratio
1100:1
Contrast Ratio
- 1100:1
Color gamut
NTSC 72%
Color gamut
- NTSC 72%
Viewing Angle (H x V)
178° x 178°
Viewing Angle (H x V)
- 178° x 178°
Response Time
8ms (G to G)
Response Time
- 8ms (G to G)
Surface Treatment (Haze)
28%
Surface Treatment (Haze)
- 28%
Lifetime Operation
50,000 Hrs (min)
Lifetime Operation
- 50,000 Hrs (min)
Operation Hours (Hours/Day)
24/7
Operation Hours (Hours/Day)
- 24/7
Orientation
Portrait or Landscape
Orientation
- Portrait or Landscape
TOUCH PANEL
Available object size for touch
6mm
Available object size for touch
- 6mm
Reponse Time
10ms
Reponse Time
- 10ms
Accuracy
2mm 0.2mm
Accuracy
- 2mm 0.2mm
Interface
USB 2.0
Interface
- USB 2.0
Protection Glass Thickness
3.2T (Anti-Glare)
Protection Glass Thickness
- 3.2T (Anti-Glare)
Protection Glass Transmission
83%
Protection Glass Transmission
- 83%
Operating System Support
Win 8.1, Win 10, Linux (Kernel v3.0 above)
Operating System Support
- Win 8.1, Win 10, Linux (Kernel v3.0 above)
Multi touch point
Max 40 Points
Multi touch point
- Max 40 Points
CONNECTIVITY
HDMI
Yes (2), HDCP2.2/1.4
HDMI
- Yes (2), HDCP2.2/1.4
DP
Yes (1), HDCP2.2/1.3
DP
- Yes (1), HDCP2.2/1.3
RS232C In
Yes (1)
RS232C In
- Yes (1)
RJ45 (LAN)
Yes (1)
RJ45 (LAN)
- Yes (1)
IR In
Yes (1)
IR In
- Yes (1)
USB
USB2.0 Type A (2)
USB
- USB2.0 Type A (2)
DP Out
Yes (1), Input HDMI1/2/DP/OPS
DP Out
- Yes (1), Input HDMI1/2/DP/OPS
Audio Out
Yes (1)
Audio Out
- Yes (1)
Touch USB
USB2.0 Type-B (1)
Touch USB
- USB2.0 Type-B (1)
Externel Speaker Out
Yes (6ohm)
Externel Speaker Out
- Yes (6ohm)
RS232C OUT
Yes (1)
RS232C OUT
- Yes (1)
OPS type compatible
Yes (Piggyback)
OPS type compatible
- Yes (Piggyback)
MECHANICAL
Bezel Color
Black
Bezel Color
- Black
Bezel Width
33.5/33.4/33.4/38 mm
Bezel Width
- 33.5/33.4/33.4/38 mm
Weight
78.0 lbs/34.5kg
Weight
- 78.0 lbs/34.5kg
Shipping Weight
87.7 lbs/39.8kg
Shipping Weight
- 87.7 lbs/39.8kg
Monitor Dimension (W x H x D)
50.3 x 29.6 x 1.8 in/1276.4 x 751.9 x 44.9 mm
Monitor Dimension (W x H x D)
- 50.3 x 29.6 x 1.8 in/1276.4 x 751.9 x 44.9 mm
Shipping Dimensions (W x H x D)
55.5 x 34.6 x 8.1 in/1410 x 880 x 207 mm
Shipping Dimensions (W x H x D)
- 55.5 x 34.6 x 8.1 in/1410 x 880 x 207 mm
VESATM Standard Mount Interface
300 x 300
VESATM Standard Mount Interface
- 300 x 300
Power Consumption (Smart Enegy Saving)
74W
Power Consumption (Smart Enegy Saving)
- 74W
Power Consumption (DPM / Power Off)
Less than 0.5W
Power Consumption (DPM / Power Off)
- Less than 0.5W
HARDWARE FEATURES
Internal Memory
8GB (System 4GB + Available 3.6GB)
Internal Memory
- 8GB (System 4GB + Available 3.6GB)
Temperature Sensor
Yes
Temperature Sensor
- Yes
Auto Brightness sensor
Yes
Auto Brightness sensor
- Yes
Local Key Operation
Yes
Local Key Operation
- Yes
Operation Temperature
32°F to 104°F/0°C to 40°C
Operation Temperature
- 32°F to 104°F/0°C to 40°C
Operation Humidity
10% to 80%
Operation Humidity
- 10% to 80%
SOFTWARE FEATURES
webOS Signage
Version 4.1
webOS Signage
- Version 4.1
Local Contents Scheduling
Yes
Local Contents Scheduling
- Yes
Group Manager
Yes
Group Manager
- Yes
USB Plug & Play
Yes
USB Plug & Play
- Yes
Fail over
Yes
Fail over
- Yes
Booting Logo Image
Yes
Booting Logo Image
- Yes
No Signal Image
Yes
No Signal Image
- Yes
RS-232C Sync
Yes
RS-232C Sync
- Yes
Local Network Sync
Yes
Local Network Sync
- Yes
PIP
Yes
PIP
- Yes
PBP
Yes
PBP
- Yes
Video Tag
Yes
Video Tag
- Yes
Play via URL
Yes
Play via URL
- Yes
Screen Rotation
Yes
Screen Rotation
- Yes
External Input Rotation
Yes
External Input Rotation
- Yes
Gapless Playback
Yes
Gapless Playback
- Yes
Tile Mode Setting
Yes
Tile Mode Setting
- Yes
Setting Data Cloning
Yes
Setting Data Cloning
- Yes
SNMP
Yes
SNMP
- Yes
ISM Method
Yes
ISM Method
- Yes
Auto Set ID
Yes
Auto Set ID
- Yes
Status Mailing
Yes
Status Mailing
- Yes
Control Manager
Yes
Control Manager
- Yes
Crestron Inside
Yes
Crestron Inside
- Yes
Smart Energy Saving
Yes
Smart Energy Saving
- Yes
PM mode
Yes
PM mode
- Yes
Wake on LAN
Yes
Wake on LAN
- Yes
HDMI-CEC
Yes
HDMI-CEC
- Yes
SI Server Setting
Yes
SI Server Setting
- Yes
webRTC
Yes
webRTC
- Yes
Pro:Idiom
Yes
Pro:Idiom
- Yes
ELECTRICAL
Power Supply
AC 100-240 V~, 50/60 Hz
Power Supply
- AC 100-240 V~, 50/60 Hz
Power Type
Built-In Power
Power Type
- Built-In Power
Power Consumption (Typ.)
105W
Power Consumption (Typ.)
- 105W
Power Consumption (Max.)
145W
Power Consumption (Max.)
- 145W
Power Consumption (Smart Enegy Saving)
74W
Power Consumption (Smart Enegy Saving)
- 74W
Power Consumption (DPM / Power Off)
Less than 0.5W
Power Consumption (DPM / Power Off)
- Less than 0.5W
CERTIFICATIONS
FCC (Regulatory)
FCC Class "A" (NRTL)
FCC (Regulatory)
- FCC Class "A" (NRTL)
ErP (Environmental)
EPA 8.0
ErP (Environmental)
- EPA 8.0
LG SOFTWARE & SERVICES*
SuperSign CMS
Yes
SuperSign CMS
- Yes
SuperSign Control / Control+
Yes
SuperSign Control / Control+
- Yes
Signage365Care
Yes
Signage365Care
- Yes
*
LG SuperSign CMS, Control+ and Signage365Care are optional paid Software/Services.
*
- LG SuperSign CMS, Control+ and Signage365Care are optional paid Software/Services.
Warranty & Other
Standard Warranty
3 Years Parts & Labor
Standard Warranty
- 3 Years Parts & Labor
UPC
719192641341
UPC
- 719192641341
Basic Accessories
Power Cord 1.55 M*1, USB Cable (Type A-Type B) 1.8 M*1, HDMI Cable 3 M*1, User Manual, QSG, Remote Controller (include battery 2ea), RS232C cable, IR Receiver , Magnet Sheet (3ea)
Basic Accessories
- Power Cord 1.55 M*1, USB Cable (Type A-Type B) 1.8 M*1, HDMI Cable 3 M*1, User Manual, QSG, Remote Controller (include battery 2ea), RS232C cable, IR Receiver , Magnet Sheet (3ea)
Optional Accessories
Wall bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSF), SP-5200
Optional Accessories
- Wall bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSF), SP-5200
Item & Dimensions
Manufacturer
LG Appliances
Manufacturer
- LG Appliances
The Misc 55" Ips Uhd Multi Touch Screen Digital Display With Webos 4.1 Smart Signage Platform, Anti-Shatter Glass, Conformal Coating & Embedded Group Manager, made by LG Appliances,
is brought to you by Simon's Furniture. Simon's Furniture is a local furniture store, serving the Boston, Franklin, Wrentham, Norfolk, Attleboro, Bellingham, Foxboro, Holliston, Hopkinton, Medfield, Medway, Milford, Millis, Plainville, Walpole Massachusetts and Providence, Rhode Island area. Product availability may vary.
Contact us for the most current availability on this product.
Collection Details
The Misc collection is an amazing option if you are looking for
furniture.
Our store serves the Boston, Franklin, Wrentham, Norfolk, Attleboro, Bellingham, Foxboro, Holliston, Hopkinton, Medfield, Medway, Milford, Millis, Plainville, Walpole Massachusetts and Providence, Rhode Island area.
Reference #: 55TC3CGH
