32'' Tn5j Series Fhd Ips In-Cell Mutli-Touch Display With Webos™ 6.0, 500 Nits Brightness

Name: Misc Miscellaneous
Brand: LG Appliances

Misc Collection by LG Appliances

SKU: 32TNF5JB

Be the first to write a review

Where Can I See This Product in Store?

This product is not on display in our showrooms.

Estimated Delivery Price

Enter your zip code to get a delivery estimate.

Disclaimer

add

Description

10 Points of Multi-Touch
The 32TNF5J-B provides a more realistic touch sensation since it can recognize up to 10 points of multi-touch at once.
24hrs / 7days
TNF5J's excellent durability allows for use in kiosks that require a full day of operation.
45-degree Tilt
32TNF5J-B has a max tilt of 45 degrees (screen up), which is great for using at waste level or lower.
Design Flexibility
This slim touch display can be portrait or landscape to meet your implimation needs, while webOS™ 6.0 smart signage platform lets you create great applications.
Wide Viewing Angle
IPS panel technology provides better control of the liquid crystals, which in turn allows the screen to be viewed at virtually any angle.
*Image simulation for illustration purposes only.
Slim Design
The In-Cell Touch Open Frame has a touch function built into the display, allowing for the implementation of a slim design and a narrow bezel compared to general touch products that require additional touch parts (Film).
*Image simulation for illustration purposes only.
High-Performance with webOS™ 6.0
32TNF5J-B features LG's webOS™ 6.0 smart signage platform that enhances user convenience with intuitive Graphic User Interface (GUI). It provides System Integrators (SI) or/and developers simple app development tools such as SDK (Software Development Kit), SCAP, & sample applications.
*Image simulation for illustration purposes only.

Portrait, Landscape and 45° Tilt
Multi-Touch Point : Max. 10 Points
WebOS™ 6.0, Pro:Idiom, Embedded CMS, Compatible with LG Supersign Software
500 nits brightness
32" Full HD (1920x1080) IPS Display
Operation 24/7 with Life up to 50,000 Hours

Rebates

view available rebates

32'' Tn5j Series Fhd Ips In-Cell Mutli-Touch Display With Webos™ 6.0, 500 Nits Brightness

Misc Collection

Specifications

Features

Portrait, Landscape and 45° Tilt, Multi-Touch Point : Max. 10 Points, WebOS™ 6.0, Pro:Idiom, Embedded CMS, Compatible with LG Supersign Software, 500 nits brightness, 32" Full HD (1920x1080) IPS Display, Operation 24/7 with Life up to 50,000 Hours

Portrait, Landscape and 45° Tilt
Multi-Touch Point : Max. 10 Points
WebOS™ 6.0, Pro:Idiom, Embedded CMS, Compatible with LG Supersign Software
500 nits brightness
32" Full HD (1920x1080) IPS Display
Operation 24/7 with Life up to 50,000 Hours

DISPLAY

Screen Size (Inch) 32"

Screen Size (Inch)

Panel Technology IPS Touch

Panel Technology

IPS Touch

Back Light Type Edge

Back Light Type

Edge

Aspect Ratio 16:9

Aspect Ratio

16:9

Native Resolution 1920x1080 (FHD)

Native Resolution

1920x1080 (FHD)

Refresh Rate 60Hz

Refresh Rate

60Hz

Brightness (Typ.) 500 nits

Brightness (Typ.)

500 nits

Contrast Ratio 1,000:1

Contrast Ratio

1,000:1

Color gamut NTSC 72%

Color gamut

NTSC 72%

Viewing Angle (H x V) 178 x 178

Viewing Angle (H x V)

178 x 178

Color Depth 8bit, 16.7 Million colors

Color Depth

8bit, 16.7 Million colors

Response Time 9ms (G to G)

Response Time

9ms (G to G)

Surface Treatment(Haze) Haze 3%

Surface Treatment(Haze)

Haze 3%

Life time Up to 50,000 Hrs

Life time

Up to 50,000 Hrs

Operation Hours (Hours/Day) 24/7

Operation Hours (Hours/Day)

24/7

Portrait / Landscape Yes / Yes

Portrait / Landscape

Yes / Yes

Available object size for touch Greater than 0.6 mm

Available object size for touch

Greater than 0.6 mm

Reponse Time( PC Win10, Education Mode) Less than 90 ms

Reponse Time( PC Win10, Education Mode)

Less than 90 ms

Accuracy (Typ.) 3.5mm

Accuracy (Typ.)

3.5mm

Interface USB2.0

Interface

USB2.0

Active Pen Interface No

Active Pen Interface

Operating System Support Win 10

Operating System Support

Win 10

Multi touch points Max 10 Points

Multi touch points

Max 10 Points

CONNECTIVITY

HDMI IN Yes (x2), HDCP1.4

HDMI IN

Yes (x2), HDCP1.4

RS232C In Yes

RS232C In

RJ45(LAN) IN Yes

RJ45(LAN) IN

IR In Yes

IR In

USB IN Yes (USB2.0 Type A)

USB IN

Yes (USB2.0 Type A)

Audio Out Yes

Audio Out

Touch USB USB2.0 Type B(1)

Touch USB

USB2.0 Type B(1)

Externel Speaker Out No

Externel Speaker Out

Daisy Chain No

Daisy Chain

FEATURES

Internal Memory (eMMC) 8GB (System 5GB + Available 2.48GB)

Internal Memory (eMMC)

8GB (System 5GB + Available 2.48GB)

Wi-Fi (Built-in) No

Wi-Fi (Built-in)

Temperature Sensor Yes

Temperature Sensor

Acceleration(Gyro) Sensor Yes

Acceleration(Gyro) Sensor

OS ver. webOS6.0

OS ver.

webOS6.0

Local Contents Scheduling Yes

Local Contents Scheduling

Group Manager Yes

Group Manager

USB Plug & Play Yes

USB Plug & Play

Fail over Yes

Fail over

Booting Logo Image Yes

Booting Logo Image

No Signal Image Yes

No Signal Image

Video Tag Yes (x4)

Video Tag

Yes (x4)

Play via URL Yes

Play via URL

Screen Rotation Yes

Screen Rotation

Gapless Playback Yes

Gapless Playback

Setting Data Cloning Yes

Setting Data Cloning

SNMP Yes

SNMP

ISM Method Yes

ISM Method

Status Mailing Yes

Status Mailing

Control Manager Yes

Control Manager

Cisco Certi. Yes

Cisco Certi.

Crestron Inside Yes

Crestron Inside

Smart Energy Saving Yes

Smart Energy Saving

PM mode Yes

PM mode

Wake on LAN Yes

Wake on LAN

Network Ready Yes

Network Ready

HDMI-CEC Yes

HDMI-CEC

SI Server Setting Yes

SI Server Setting

webRTC Yes

webRTC

Pro:Idiom Yes

Pro:Idiom

MECHANICAL

Bezel Color Black

Bezel Color

Black

Bezel Width 11.3/11.3/11.3/13.2 mm

Bezel Width

11.3/11.3/11.3/13.2 mm

Weight 12.3 lbs. / 5.6 kg

Weight

12.3 lbs. / 5.6 kg

Shipping Weight 15.0 lbs. / 6.8 kg

Shipping Weight

15.0 lbs. / 6.8 kg

Dimensions (W x H x D) 28.5 x 16.5 x 1.5 in. 723.0 x 419.4 x 39.1 mm

Dimensions (W x H x D)

28.5 x 16.5 x 1.5 in. 723.0 x 419.4 x 39.1 mm

Shipping Dimensions (W x H x D) 32.0 x 20.1 x 5.6 in. 812 x 510 x 142 mm

Shipping Dimensions (W x H x D)

32.0 x 20.1 x 5.6 in. 812 x 510 x 142 mm

Handle No

Handle

Tilt (Face Up) Yes (Max 45°)

Tilt (Face Up)

Yes (Max 45°)

Conformal Coating (Power Board) Yes

Conformal Coating (Power Board)

VESATM Standard Mount Interface 200 x 200

VESATM Standard Mount Interface

200 x 200

ENVIRONMENT

Operation Temperature 0 °C to 40 °C

Operation Temperature

0 °C to 40 °C

Operation Humidity 10% to 80%

Operation Humidity

10% to 80%

ELECTRICAL

Power Supply AC 100-240 V~, 50/60 Hz

Power Supply

AC 100-240 V~, 50/60 Hz

Power Type Built-In Power

Power Type

Built-In Power

Power Consumption (Typ.) 55W

Power Consumption (Typ.)

Power Consumption (Max.) 65W

Power Consumption (Max.)

Power Consumption (British Thermal Unit) 188 BTU/Hr(Typ.), 222BTU/Hr(Max.)

Power Consumption (British Thermal Unit)

188 BTU/Hr(Typ.), 222BTU/Hr(Max.)

Power Consumption (Smart Energy Saving, ~70%) 39W

Power Consumption (Smart Energy Saving, ~70%)

Power Consumption (DPM) Less than 0.5 W

Power Consumption (DPM)

Less than 0.5 W

Power Consumption (Power Off) Less than 0.5 W

Power Consumption (Power Off)

Less than 0.5 W

LG SOFTWARE COMPATIBILITY

SuperSign CMS Yes

SuperSign CMS

SuperSign Control+ Yes

SuperSign Control+

SuperSign WB No

SuperSign WB

SuperSign Cloud Yes

SuperSign Cloud

Promota No

Promota

Mobile CMS Yes

Mobile CMS

Connected Care Yes

Connected Care

Warranty & Other

Warranty 3 Year Limited

Warranty

3 Year Limited

UPC 1 95174 02761 5

UPC

1 95174 02761 5

Safety CB / NRTL

Safety

CB / NRTL

EMC FCC Class "A"/ CE

EMC

FCC Class "A"/ CE

ErP (Environmental) Yes

ErP (Environmental)

Onscreen Display Languages English, French, German, Spanish, Italian, Korean , Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Arabic, T rk e, Polski

Onscreen Display Languages

English, French, German, Spanish, Italian, Korean , Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Arabic, T rk e, Polski

Accessories 1.5m Power Cord, 1.8m USB Cable (Type A-Type B) User Manual, QSG, Remote Control (includes 2 batteries), RS232C Adapter, IR Receiver

Accessories

1.5m Power Cord, 1.8m USB Cable (Type A-Type B) User Manual, QSG, Remote Control (includes 2 batteries), RS232C Adapter, IR Receiver

Item & Dimensions

Manufacturer LG Appliances

Manufacturer

LG Appliances
