Description
moreAll-in-One DVLED Screen with Built-in Speaker
LG's LED All-in-One LAEC series has two size of screens; 136- inch and a 163-inch. The LAEC series is offered as an all-in-one package including an embedded controller and built-in speaker. After a simple installation process that neither requires controller connections or module configuration, all you need to do is to turn on the screen with the remote control like a home TV.
High Performance with webOS™
Built-in Quad Core SoC (System on Chip) can execute several tasks at once for providing smooth content playback. Also, LG webOS™ Smart Platform enhances user convenience with intuitive GUI and provides to SI or/and developers simple app development tools* such as SDK (Software Development Kit), SCAP, sample applications.
Quick Maintenance
In case of failure related to the LED module or the system board, it can be serviced from the front. The LED module can be simply detached by the provided magnetic tool and replaced quickly without cabling.
Wireless Screen Sharing
The LAEC series is compatible with LG One:Quick Share*, a wireless screen sharing solution. It helps to simply share one's personal PC screen to the display with its button and embedded Wi-Fi**, and it can also adjust the basic setting values (volume, picture mode, auto bright, etc.) of the connected display without a remote control. * LG One:Quick Share needs to be purchased separately. ** Users need to set up SoftAP enabled at Network Menu of the Signage.
Real-Time LG ConnectedCare
Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, enabling the stable operation of clients' businesses.
Compatible with AV Control Systems
The LAEC series supports Crestron Connected®* for high compatibility with professional AV controls to achieve virtually seamless integration and automated control**, boosting business management efficiency. * Initial setting from display is required for Crestron Connected® compatibility. ** Network based control
Easy Installation
The installation process of the All-in-One Smart series is very simple. After securing cabinets (two for LAEC015, three for LAEC018), attach each LED display module to them. Lastly, plug in the power cable. This simple installation saves time and labor, thereby making users handle the LED screen with ease.
*Fixing screws or installing wall mount / accessories is needed additionally. *The image is illustrated as an example of LAEC015 model.
Versatile Installation with Dedicated Accessories
The product is offered with the necessary component including the landscape wall mount and tools for installation. The dedicated stand* is provided as an option, so that you can easily place it depending on your installation sites. Also, the LAEC series can be installed side by side in the form of 1 x N or 2 x N, up to 14 screens, suitable for its installation site and its purposes.
*Stand accessories differ by models, and need to be purchased separately. Image simulation for illustration purposes only.
Magic Remote for Easy of Use
With the LG Magic Remote, you can select and run the menu of the signage just like using a mouse and its cursor can be used as a laser pointer. In addition, through the newly added 'FREEZE' button on the remote control, users can temporarily freeze the screen while switching contents on the PC, so that users are able to have uninterrupted meetings without exposing its switching process.
*LG Magic Remote needs to be purchased separately. The FREEZE function is only available when the LAEC is connected to an external input signal. Image simulation for illustration purposes only.
LG's LED All-in-One LAEC series has two size of screens; 136- inch and a 163-inch. The LAEC series is offered as an all-in-one package including an embedded controller and built-in speaker. After a simple installation process that neither requires controller connections or module configuration, all you need to do is to turn on the screen with the remote control like a home TV.
High Performance with webOS™
Built-in Quad Core SoC (System on Chip) can execute several tasks at once for providing smooth content playback. Also, LG webOS™ Smart Platform enhances user convenience with intuitive GUI and provides to SI or/and developers simple app development tools* such as SDK (Software Development Kit), SCAP, sample applications.
Quick Maintenance
In case of failure related to the LED module or the system board, it can be serviced from the front. The LED module can be simply detached by the provided magnetic tool and replaced quickly without cabling.
Wireless Screen Sharing
The LAEC series is compatible with LG One:Quick Share*, a wireless screen sharing solution. It helps to simply share one's personal PC screen to the display with its button and embedded Wi-Fi**, and it can also adjust the basic setting values (volume, picture mode, auto bright, etc.) of the connected display without a remote control. * LG One:Quick Share needs to be purchased separately. ** Users need to set up SoftAP enabled at Network Menu of the Signage.
Real-Time LG ConnectedCare
Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, enabling the stable operation of clients' businesses.
Compatible with AV Control Systems
The LAEC series supports Crestron Connected®* for high compatibility with professional AV controls to achieve virtually seamless integration and automated control**, boosting business management efficiency. * Initial setting from display is required for Crestron Connected® compatibility. ** Network based control
Easy Installation
The installation process of the All-in-One Smart series is very simple. After securing cabinets (two for LAEC015, three for LAEC018), attach each LED display module to them. Lastly, plug in the power cable. This simple installation saves time and labor, thereby making users handle the LED screen with ease.
*Fixing screws or installing wall mount / accessories is needed additionally. *The image is illustrated as an example of LAEC015 model.
Versatile Installation with Dedicated Accessories
The product is offered with the necessary component including the landscape wall mount and tools for installation. The dedicated stand* is provided as an option, so that you can easily place it depending on your installation sites. Also, the LAEC series can be installed side by side in the form of 1 x N or 2 x N, up to 14 screens, suitable for its installation site and its purposes.
*Stand accessories differ by models, and need to be purchased separately. Image simulation for illustration purposes only.
Magic Remote for Easy of Use
With the LG Magic Remote, you can select and run the menu of the signage just like using a mouse and its cursor can be used as a laser pointer. In addition, through the newly added 'FREEZE' button on the remote control, users can temporarily freeze the screen while switching contents on the PC, so that users are able to have uninterrupted meetings without exposing its switching process.
*LG Magic Remote needs to be purchased separately. The FREEZE function is only available when the LAEC is connected to an external input signal. Image simulation for illustration purposes only.
- Supports Crestron Connected & is Compatible with One:Quick Share
- LG webOS Smart Platform
- Built-in Speakers, Embedded System Controller
- Versatile Installation with Dedicated Accessories
- 1.56 mm Pixel Pitch, 136" FHD DVLED Screen
Online Manual English 2,061K 07/07/2023
View PDF for more information
Rebates
view available rebates
Specifications
Specifications
Features
Supports Crestron Connected & is Compatible with One:Quick Share, LG webOS Smart Platform, Built-in Speakers, Embedded System Controller, Versatile Installation with Dedicated Accessories, 1.56 mm Pixel Pitch, 136" FHD DVLED Screen
- Supports Crestron Connected & is Compatible with One:Quick Share
- LG webOS Smart Platform
- Built-in Speakers, Embedded System Controller
- Versatile Installation with Dedicated Accessories
- 1.56 mm Pixel Pitch, 136" FHD DVLED Screen
PHYSICAL PARAMETERS
Pixel Configuration
Single SMD
Pixel Configuration
- Single SMD
Pixel Pitch
1.56mm
Pixel Pitch
- 1.56mm
Screen Resolution (W x H)
1,920 x 1,080
Screen Resolution (W x H)
- 1,920 x 1,080
Module Dimensions (W x H)
9.8 x 11. in. / 250 x 281.3 mm
Module Dimensions (W x H)
- 9.8 x 11. in. / 250 x 281.3 mm
No. of Modules per Screen (W x H)
12 x 6 (Total 72)
No. of Modules per Screen (W x H)
- 12 x 6 (Total 72)
Screen Dimensions (W x H x D)
118.3 x 66.6 x 2.8 in. 3,004 x 1,692 x 70 mm
Screen Dimensions (W x H x D)
- 118.3 x 66.6 x 2.8 in. 3,004 x 1,692 x 70 mm
Screen Surface Area
54.5 ft / 5.06 m
Screen Surface Area
- 54.5 ft / 5.06 m
Screen Weight
291 lbs. / 132 kg
Screen Weight
- 291 lbs. / 132 kg
Physical Pixel Density
409,600 pixels/m
Physical Pixel Density
- 409,600 pixels/m
Flatness of Cabinet
0.2mm
Flatness of Cabinet
- 0.2mm
Cabinet Material
Die-casting Aluminum
Cabinet Material
- Die-casting Aluminum
Service Access
Front
Service Access
- Front
OPTICAL SPECIFICATIONS
Max. Brightness After Calibration
500 nits
Max. Brightness After Calibration
- 500 nits
Color Temperature
3,200 - 9,300 K
Color Temperature
- 3,200 - 9,300 K
Visual Viewing Angle (Horizontal)
160°
Visual Viewing Angle (Horizontal)
- 160°
Visual Viewing Angle (Vertical)
160°
Visual Viewing Angle (Vertical)
- 160°
Brightness Uniformity
98%
Brightness Uniformity
- 98%
Color Uniformity
0.015Cx,Cy
Color Uniformity
- 0.015Cx,Cy
Contrast Ratio
3,000:1
Contrast Ratio
- 3,000:1
Processing Depth
16 bit (HDR10, HDR10 Pro)
Processing Depth
- 16 bit (HDR10, HDR10 Pro)
ELECTRICAL SPECIFICATIONS
Max Power Consumption
1,700 W , 5,800 BTU/h
Max Power Consumption
- 1,700 W , 5,800 BTU/h
Avg. Power Consumption
680 W , 2,321 BTU/h
Avg. Power Consumption
- 680 W , 2,321 BTU/h
Max Power Consumption per Unit Area
336 W/m , 1,146 BTU/h/m
Max Power Consumption per Unit Area
- 336 W/m , 1,146 BTU/h/m
Power Supply
100 to 240 Vac
Power Supply
- 100 to 240 Vac
Frame Rate
50 / 60 Hz
Frame Rate
- 50 / 60 Hz
Refresh Rate
3,960 Hz
Refresh Rate
- 3,960 Hz
OPERATION SPECIFICATIONS
Lifetime (Half brightness)
Up to 100,000 Hours
Lifetime (Half brightness)
- Up to 100,000 Hours
Operating Temperature
32°F to 104°F / 0°C to +40°C
Operating Temperature
- 32°F to 104°F / 0°C to +40°C
Operating Humidity
10-80% RH
Operating Humidity
- 10-80% RH
IP Rating (Front / Rear)
IP30 / IP20
IP Rating (Front / Rear)
- IP30 / IP20
Speakers
Speakers
Built-in (9 W + 9 W)
Speakers
- Built-in (9 W + 9 W)
CERTIFICATIONS
CERTIFICATIONS
CE, FCC, ETL, CB
CERTIFICATIONS
- CE, FCC, ETL, CB
ENVIRONMENT
Environment
RoHS, REACH
Environment
- RoHS, REACH
LED CONTROLLER
LED Controller
Embedded
LED Controller
- Embedded
Item & Dimensions
