Description
Curve Effect Available
The mechanical connection between the two panels is secured by an angle adapter system and a fast lock, adjustable by 10 degrees in concave areas and 5 degrees in convex areas.
Stacking & Hanging System Available
Installation can be performed by stacking or hanging, using the optional accessories (single, double, triple beams) for customization to the studio environment.
Broadcast Quality Available
Clear color reproduction, low latency of video processing, and HDR capability.
Brompton LED Processor & Data Distribution
LBCK supports use of Brompton controllers, which are well know in the Media and Entertianment industry.
Easy Installation & Maintenance
The module can be easily removed using the dedicated tool (with front or rear selective service access). The positioning pins and magnets help perform panel adjustments accurately and quickly, ensuring seamless screen assembly.
The mechanical connection between the two panels is secured by an angle adapter system and a fast lock, adjustable by 10 degrees in concave areas and 5 degrees in convex areas.
Stacking & Hanging System Available
Installation can be performed by stacking or hanging, using the optional accessories (single, double, triple beams) for customization to the studio environment.
Broadcast Quality Available
Clear color reproduction, low latency of video processing, and HDR capability.
Brompton LED Processor & Data Distribution
LBCK supports use of Brompton controllers, which are well know in the Media and Entertianment industry.
Easy Installation & Maintenance
The module can be easily removed using the dedicated tool (with front or rear selective service access). The positioning pins and magnets help perform panel adjustments accurately and quickly, ensuring seamless screen assembly.
- Easy Installation and Maintenance
- Front or Rear Serviceability
- 1,500 nit Brightness
- Curve Effect Available
- Brompton LED Processor & Data Distribution
- Stacking & Hanging System Available
Rebates
view available rebates
Lbcj Wall Direct View Led For Virtual Production
Misc Collection
Specifications
Specifications
Features
Easy Installation and Maintenance, Front or Rear Serviceability, 1,500 nit Brightness, Curve Effect Available, Brompton LED Processor & Data Distribution, Stacking & Hanging System Available
- Easy Installation and Maintenance
- Front or Rear Serviceability
- 1,500 nit Brightness
- Curve Effect Available
- Brompton LED Processor & Data Distribution
- Stacking & Hanging System Available
PHYSICAL PARAMETERS
Pixel Configuration
3 in 1
Pixel Configuration
- 3 in 1
Pixel Pitch (mm)
2.60
Pixel Pitch (mm)
- 2.60
Module Resolution (W x H)
96 x 96
Module Resolution (W x H)
- 96 x 96
Module Dimensions (W x H, mm)
250 x 250
Module Dimensions (W x H, mm)
- 250 x 250
Weight per Module (kg)
0.59
Weight per Module (kg)
- 0.59
No. of Modules per Cabinet (W x H)
2 x 2
No. of Modules per Cabinet (W x H)
- 2 x 2
Cabinet Resolution (W x H)
192 x 192
Cabinet Resolution (W x H)
- 192 x 192
Cabinet Dimensions (W x H x D, mm)
500 x 500 x 75.5
Cabinet Dimensions (W x H x D, mm)
- 500 x 500 x 75.5
Cabinet Surface Area (m )
0.250
Cabinet Surface Area (m )
- 0.250
Weight per Cabinet (kg/Cabinet)
5.9
Weight per Cabinet (kg/Cabinet)
- 5.9
Weight per Square Meter (kg/m )
24.0
Weight per Square Meter (kg/m )
- 24.0
Physical Pixel Density (pixels/m )
147,456
Physical Pixel Density (pixels/m )
- 147,456
Flatness of Cabinet (mm)
0.15
Flatness of Cabinet (mm)
- 0.15
Cabinet Material
Die Casting Magnesium Alloy
Cabinet Material
- Die Casting Magnesium Alloy
Service Access
Front or Rear (select one only)
Service Access
- Front or Rear (select one only)
OPTICAL SPECIFICATIONS
Max. Brightness (After Calibration, nit)
1,500
Max. Brightness (After Calibration, nit)
- 1,500
Color Temperature (K)
2,000-11,000
Color Temperature (K)
- 2,000-11,000
Visual Viewing Angle (H x V)
160 x 160
Visual Viewing Angle (H x V)
- 160 x 160
Brightness Uniformity
97%
Brightness Uniformity
- 97%
Color Uniformity
0.003 Cx,Cy
Color Uniformity
- 0.003 Cx,Cy
Contrast Ratio
5,000:1
Contrast Ratio
- 5,000:1
Processing Depth (bit)
16 (PQ, HLG)
Processing Depth (bit)
- 16 (PQ, HLG)
ELECTRICAL SPECIFICATIONS
Power Consumption (W/Cabinet, Max.)
180
Power Consumption (W/Cabinet, Max.)
- 180
Power Consumption (W/Cabinet, Avg.)
60
Power Consumption (W/Cabinet, Avg.)
- 60
Power Consumption (W/m , Max.)
720
Power Consumption (W/m , Max.)
- 720
Heat Dissipation (BTU/h/Cabinet, Max.)
614
Heat Dissipation (BTU/h/Cabinet, Max.)
- 614
Heat Dissipation (BTU/h/Cabinet, Avg.)
205
Heat Dissipation (BTU/h/Cabinet, Avg.)
- 205
Heat Dissipation (BTU/h/m , Max.)
2,457
Heat Dissipation (BTU/h/m , Max.)
- 2,457
Power Supply (V)
100 to 240
Power Supply (V)
- 100 to 240
Frame Rate (Hz)
50 / 60
Frame Rate (Hz)
- 50 / 60
Refresh Rate (Hz)
7,680
Refresh Rate (Hz)
- 7,680
OPERATION SPECIFICATIONS
LED Lifetime (Half brightness)
100,000
LED Lifetime (Half brightness)
- 100,000
Operating Temperature (°C)
-10 to +45
Operating Temperature (°C)
- -10 to +45
Operating Humidity
0-80% RH
Operating Humidity
- 0-80% RH
IP Rating Front / Rear
IP30 / IP30
IP Rating Front / Rear
- IP30 / IP30
CERTIFICATION
Certification
CE / FCC / ETL
Certification
- CE / FCC / ETL
ENVIRONMENT
Environment
RoHS, REACH
Environment
- RoHS, REACH
CONTROLLER
Controller
Brompton SX40
Controller
- Brompton SX40
90 DEGREE CORNER CUT
90 Degree corner cut
No
90 Degree corner cut
- No
Item & Dimensions
Manufacturer
LG Appliances
Manufacturer
- LG Appliances
The Misc Lbcj Wall Direct View Led For Virtual Production, made by LG Appliances,
