Description
Appropriate Display Brightness
With recommended brightness for indoor display, the ML5K series clearly delivers content and attracts public attention, making it the most suitable display for marketing in hospital, meeting rooms, airports, retail, shopping malls, etc.
*Actual images available may differ from the example images shown. *43ML5K has 500 nit and 32ML5K has 400 nit.
High-Performance with webOS
LG webOS platform enhances user convenience with intuitive GUI and simple app development tools.
Conformal Coating
In various places the ML5K series is unable to avoid exposure to environments containing dust, humidity, etc. which may hamper performance over time. The conformal coating on power board reduces these risks by protecting ML5K series from salt, dust, iron powder, humidity, etc.
*Actual images (signage display) available may differ from the example images shown.
Compatible with AV Control System
The ML5K series has supported Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.
*Network based control.
PoE++ Mode
Install 32ML5K easily without AC power plugs and sockets. PoE++ (Power over Ethernet) mode is available on 32ML5K, which brings an integrated network and power connection via RJ45, without using an electrical outlet.
*32ML5K only *PSE (Power Sourcing Equipment) required when using PoE++ Mode *PSE Equipment is not included. *AC Power mode : 400 nit, PoE++ Mode : 200 nit
With recommended brightness for indoor display, the ML5K series clearly delivers content and attracts public attention, making it the most suitable display for marketing in hospital, meeting rooms, airports, retail, shopping malls, etc.
*Actual images available may differ from the example images shown. *43ML5K has 500 nit and 32ML5K has 400 nit.
High-Performance with webOS
LG webOS platform enhances user convenience with intuitive GUI and simple app development tools.
Conformal Coating
In various places the ML5K series is unable to avoid exposure to environments containing dust, humidity, etc. which may hamper performance over time. The conformal coating on power board reduces these risks by protecting ML5K series from salt, dust, iron powder, humidity, etc.
*Actual images (signage display) available may differ from the example images shown.
Compatible with AV Control System
The ML5K series has supported Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.
*Network based control.
PoE++ Mode
Install 32ML5K easily without AC power plugs and sockets. PoE++ (Power over Ethernet) mode is available on 32ML5K, which brings an integrated network and power connection via RJ45, without using an electrical outlet.
*32ML5K only *PSE (Power Sourcing Equipment) required when using PoE++ Mode *PSE Equipment is not included. *AC Power mode : 400 nit, PoE++ Mode : 200 nit
- Supports Crestron Connected
- FHD Resolution (1920x1080) Creates Crisps, Clear Images for Dr. & Patients
- LG WebOS 6.0 Platform
- Portrait & Landscape
- 400 nit Brightness and 1% Haze Surface Treatment for Clear Viewing Indoors
- Up to 50,000 hours lifetime 24/7
Rebates
view available rebates
32'' Ml5k Series Fhd Healthcare Digital Signage
Misc Collection
Specifications
Specifications
Features
Supports Crestron Connected, FHD Resolution (1920x1080) Creates Crisps, Clear Images for Dr. & Patients, LG WebOS 6.0 Platform, Portrait & Landscape, 400 nit Brightness and 1% Haze Surface Treatment for Clear Viewing Indoors, Up to 50,000 hours lifetime 24/7
- Supports Crestron Connected
- FHD Resolution (1920x1080) Creates Crisps, Clear Images for Dr. & Patients
- LG WebOS 6.0 Platform
- Portrait & Landscape
- 400 nit Brightness and 1% Haze Surface Treatment for Clear Viewing Indoors
- Up to 50,000 hours lifetime 24/7
PANEL
Diagonal
32"
Diagonal
- 32"
Panel Technology
IPS
Panel Technology
- IPS
Back Light Type
Direct
Back Light Type
- Direct
Aspect Ratio
16:9
Aspect Ratio
- 16:9
Native Resolution
1920 x 1080 (FHD)
Native Resolution
- 1920 x 1080 (FHD)
Refresh Rate
60 Hz
Refresh Rate
- 60 Hz
Brightness (Typ.)
AC Mode 400 nits (Typ.) - PoE Mode 200 nits (Typ.)
Brightness (Typ.)
- AC Mode 400 nits (Typ.) - PoE Mode 200 nits (Typ.)
Contrast Ratio
1200:1
Contrast Ratio
- 1200:1
Dynamic CR
1,000,000:1
Dynamic CR
- 1,000,000:1
Color Gamut
BT709 95%
Color Gamut
- BT709 95%
Viewing Angle(H x V)
178° x 178°
Viewing Angle(H x V)
- 178° x 178°
Color Depth
8 bit, 16.7 Million Colors
Color Depth
- 8 bit, 16.7 Million Colors
Response Time (G to G)
9ms
Response Time (G to G)
- 9ms
Surface Treatment(Haze)
Haze 1%
Surface Treatment(Haze)
- Haze 1%
Life time
Up to 50,000 Hrs
Life time
- Up to 50,000 Hrs
Operation Hours (Hours/Day)
24/7
Operation Hours (Hours/Day)
- 24/7
Portrait / Landscape
Yes / Yes
Portrait / Landscape
- Yes / Yes
CONNECTIVITY
HDMI IN
Yes (x2) HDMI1 / HDMI2: HDCP 2.2/1.4
HDMI IN
- Yes (x2) HDMI1 / HDMI2: HDCP 2.2/1.4
DP In
No
DP In
- No
DVI-D In
No
DVI-D In
- No
Audio In
No
Audio In
- No
RS232C In
Yes (x1), 4-pin 3.5 mm Jack
RS232C In
- Yes (x1), 4-pin 3.5 mm Jack
RJ45 (LAN)
Yes (x1), Includes PoE++
RJ45 (LAN)
- Yes (x1), Includes PoE++
IR In
Yes (x1)
IR In
- Yes (x1)
USB in
USB2.0 Type A(1)
USB in
- USB2.0 Type A(1)
HDMI Out
No
HDMI Out
- No
Audio Out
Yes (x1)
Audio Out
- Yes (x1)
RS232C OUT
Yes (x1), 4-pin 3.5 mm Jack
RS232C OUT
- Yes (x1), 4-pin 3.5 mm Jack
MECHANICAL
Bezel Color
Black
Bezel Color
- Black
Bezel Width
T/R/L: 13.0 mm, B: 18.0 mm
Bezel Width
- T/R/L: 13.0 mm, B: 18.0 mm
Weight (Head)
12.6 lbs. / 5.7 kg
Weight (Head)
- 12.6 lbs. / 5.7 kg
Packed Weight
16.3 lbs. / 7.4 kg
Packed Weight
- 16.3 lbs. / 7.4 kg
Monitor Dimensions (W x H x D)
28.7 x 16.9 x 2.2 in. (729.4 x 428.9 x 55.5 mm)
Monitor Dimensions (W x H x D)
- 28.7 x 16.9 x 2.2 in. (729.4 x 428.9 x 55.5 mm)
Carton Dimensions (W x H x D)
31.9 x 20.1 x 5.2 in.(810.0 x 510.0 x 132.0 mm)
Carton Dimensions (W x H x D)
- 31.9 x 20.1 x 5.2 in.(810.0 x 510.0 x 132.0 mm)
Handle
No
Handle
- No
Tilt (Face Down)
No
Tilt (Face Down)
- No
VESATM Standard Mount Interface
200 x 200
VESATM Standard Mount Interface
- 200 x 200
HARDWARE FEATURES
Internal Memory (eMMC)
16 GB
Internal Memory (eMMC)
- 16 GB
Wi-Fi (Built-in)
Yes
Wi-Fi (Built-in)
- Yes
Temperature Sensor
Yes
Temperature Sensor
- Yes
Auto Brightness sensor
Yes
Auto Brightness sensor
- Yes
Local Key Operation
Yes
Local Key Operation
- Yes
Speaker (Built-in)
Yes (3W x 2)
Speaker (Built-in)
- Yes (3W x 2)
SOFTWARE FEATURES
OS Version
webOS 6.0
OS Version
- webOS 6.0
Local Contents Scheduling
Yes
Local Contents Scheduling
- Yes
Group Manager
Yes
Group Manager
- Yes
USB Plug & Play
Yes
USB Plug & Play
- Yes
Fail over
Yes
Fail over
- Yes
Booting Logo Image
Yes
Booting Logo Image
- Yes
No Signal Image
Yes
No Signal Image
- Yes
RS232C Sync
Yes
RS232C Sync
- Yes
Local Network Sync
Yes
Local Network Sync
- Yes
PIP
No
PIP
- No
PBP
No
PBP
- No
Screen Share
Yes
Screen Share
- Yes
Video Tag
Yes (x4)
Video Tag
- Yes (x4)
Play via URL
Yes
Play via URL
- Yes
Screen Rotation
Yes
Screen Rotation
- Yes
External Input Rotation
Yes
External Input Rotation
- Yes
Gapless Playback
Yes
Gapless Playback
- Yes
Tile Mode Setting
Yes (15 x 15 Max)
Tile Mode Setting
- Yes (15 x 15 Max)
Data Cloning
Yes
Data Cloning
- Yes
SNMP
Yes
SNMP
- Yes
ISM Method
Yes
ISM Method
- Yes
Auto Set ID
Yes
Auto Set ID
- Yes
Status Mailing
Yes
Status Mailing
- Yes
Control Manager
Yes
Control Manager
- Yes
Crestron Inside
Yes
Crestron Inside
- Yes
Smart Energy Saving
Yes
Smart Energy Saving
- Yes
PM Modes (e.g., Network Ready)
Yes
PM Modes (e.g., Network Ready)
- Yes
Wake on LAN
Yes
Wake on LAN
- Yes
Beacon
Yes
Beacon
- Yes
HDMI-CEC
Yes
HDMI-CEC
- Yes
SI Server Setting
Yes
SI Server Setting
- Yes
webRTC
Yes
webRTC
- Yes
Pro:Idiom
Yes
Pro:Idiom
- Yes
OPERATION CONDITIONS
Operation Temperature
32 °F to 104 °F / 0 °C to 40 °C
Operation Temperature
- 32 °F to 104 °F / 0 °C to 40 °C
Operation Humidity
10 % to 80 %
Operation Humidity
- 10 % to 80 %
ELECTRICAL
Power Supply
120 Vac, 50/60 Hz or PoE++: 41.1-57 V
Power Supply
- 120 Vac, 50/60 Hz or PoE++: 41.1-57 V
Power Type
Built-In Power / PoE++
Power Type
- Built-In Power / PoE++
Power Consumption (Typ.)
55 W
Power Consumption (Typ.)
- 55 W
Power Consumption (Max.)
75 W
Power Consumption (Max.)
- 75 W
Power Consumption (British Thermal Unit)
188 BTU/Hr (Typ.) / 256BTU/Hr (Max.)
Power Consumption (British Thermal Unit)
- 188 BTU/Hr (Typ.) / 256BTU/Hr (Max.)
Power Consumption (Smart Energy Saving)
38.5 W
Power Consumption (Smart Energy Saving)
- 38.5 W
Power Consumption (DPM)
1 W
Power Consumption (DPM)
- 1 W
Power Consumption (Power Off)
1 W
Power Consumption (Power Off)
- 1 W
PoE Type
PoE++ : Type3 802.3bt
PoE Type
- PoE++ : Type3 802.3bt
PoE Power Class
Class 6
PoE Power Class
- Class 6
REGULATORY & CERTIFICATIONS
Safety
NRTL
Safety
- NRTL
EMC
FCC Class "A"
EMC
- FCC Class "A"
Energy Star
Yes
Energy Star
- Yes
UL Listed for Hospitals
UL62368-1
UL Listed for Hospitals
- UL62368-1
OPS Compatibility
OPS Type Compatible
No
OPS Type Compatible
- No
OPS Power Built-in
No
OPS Power Built-in
- No
LG SOFTWARE COMPATIBILITY
SuperSign WB
Yes
SuperSign WB
- Yes
SuperSign Control / Control+
Yes / Yes
SuperSign Control / Control+
- Yes / Yes
SuperSign CMS
Yes
SuperSign CMS
- Yes
Mobile CMS
Yes
Mobile CMS
- Yes
Connected Care
Yes
Connected Care
- Yes
Languages
Onscreen Display
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Polski, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, T rk e, Arabic
Onscreen Display
- English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Polski, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, T rk e, Arabic
Warranty & Other
Warranty
2 Year Limited
Warranty
- 2 Year Limited
UPC
195174044278
UPC
- 195174044278
Basic Accessories
Remote Control including battery (x2), Power Cord, QSG, Regulation Book, Phone to RS-232C Adapter
Basic Accessories
- Remote Control including battery (x2), Power Cord, QSG, Regulation Book, Phone to RS-232C Adapter
Item & Dimensions
Manufacturer
LG Appliances
Manufacturer
- LG Appliances
The Misc 32'' Ml5k Series Fhd Healthcare Digital Signage, made by LG Appliances,
