Ge® 36" Built-In Touch Control Electric Cooktop
SKU: JP5036DJBB
Where Can I See This Product in Store?
moreThis product is not on display in our showrooms.
Estimated Delivery Price
Enter your zip code to get a delivery estimate.
Ask a Question
lessDimensions:
36.0" W
×
20.375" D
×
5.5625" H
| Width (side to side) | 36.0 |
| Depth (front to back) | 20.375 |
| Height (bottom to top) | 5.5625 |
Disclaimer
Description
moreFive radiant cooking elements
Cook foods quickly and evenly on this sleek, glass surface
Digital Touch Controls
Accurately control your heating on a surface that's easy to clean
Power Boil Tri-Ring Element
Use different pan sizes on this 3,000-watt flexible element
Power Boil Dual-Ring Element
Use different pan sizes on this 2,400-watt flexible element
Kitchen timer
Helps coordinate meal preparation and cooking
Keep Warm Setting
A fully functional 6" element has the power to boil water and can keep food warm thanks to GE's lowest heat setting
Melt Setting
Gently melt delicate foods without scorching thanks to a convenient melt setting
Control lock capability
Protects against unintended activation
Red LED with Black Glass Surface
Achieve a modern look that complements the entire kitchen
Hot surface indicator lights
Know when elements are too hot to touch with a quick glance
Fit Guarantee
Replacing a similar cooktop from GE Appliances or another brand? GE cooktops are guaranteed for an exact fit or GE Appliances will pay up to $100 toward modifications. See offer criteria and details
Cook foods quickly and evenly on this sleek, glass surface
Digital Touch Controls
Accurately control your heating on a surface that's easy to clean
Power Boil Tri-Ring Element
Use different pan sizes on this 3,000-watt flexible element
Power Boil Dual-Ring Element
Use different pan sizes on this 2,400-watt flexible element
Kitchen timer
Helps coordinate meal preparation and cooking
Keep Warm Setting
A fully functional 6" element has the power to boil water and can keep food warm thanks to GE's lowest heat setting
Melt Setting
Gently melt delicate foods without scorching thanks to a convenient melt setting
Control lock capability
Protects against unintended activation
Red LED with Black Glass Surface
Achieve a modern look that complements the entire kitchen
Hot surface indicator lights
Know when elements are too hot to touch with a quick glance
Fit Guarantee
Replacing a similar cooktop from GE Appliances or another brand? GE cooktops are guaranteed for an exact fit or GE Appliances will pay up to $100 toward modifications. See offer criteria and details
- Power Boil Dual-Ring Element
- Control lock capability
- Digital Touch Controls
- Red LED with Black Glass Surface
- Hot surface indicator lights
- Power Boil Tri-Ring Element
- Kitchen timer
- Five radiant cooking elements
- Keep Warm Setting
- Melt Setting
Rebates
view available rebates
Ge® 36" Built-In Touch Control Electric Cooktop
Electric Ranges Collection
Specifications
Specifications
Product
Sabbath Mode
No
Sabbath Mode
- No
Wifi Enabled
No
Wifi Enabled
- No
Appliance Fuel Type
Electric
Appliance Fuel Type
- Electric
Appliance Color
Black
Appliance Color
- Black
Induction
No
Induction
- No
ADA Compliant
Yes
ADA Compliant
- Yes
Energy Star Compliant
No
Energy Star Compliant
- No
Dimensions
Height (bottom to top)
5.5625" H
Height (bottom to top)
- 5.5625" H
Width (side to side)
36.0" W
Width (side to side)
- 36.0" W
Depth (front to back)
20.375" D
Depth (front to back)
- 20.375" D
Features & Function
Number of Burners
5
Number of Burners
- 5
Oven Features
ADA Compliant
Oven Features
- ADA Compliant
Maximum Spin Speed (RPM)
-1.0
Maximum Spin Speed (RPM)
- -1.0
Style Elements
Color Family
Black
Color Family
- Black
Color Name
Black
Color Name
- Black
FILTER
App Filter - Cabinet Width
Cooking 36 in.
App Filter - Cabinet Width
- Cooking 36 in.
App Filter - Cooktop Type
Radiant Smoothtop
App Filter - Cooktop Type
- Radiant Smoothtop
App Filter - Fuel Type
Electric
App Filter - Fuel Type
- Electric
App Filter - Control Type
Digital touch
App Filter - Control Type
- Digital touch
APPEARANCE
Frame Color / Material
Stainless Steel
Frame Color / Material
- Stainless Steel
Color Appearance
Black
Color Appearance
- Black
Frameless
Yes
Frameless
- Yes
Control Knobs
Gloss Black
Control Knobs
- Gloss Black
POWER / RATINGS
Recommended Circuit Breaker (Amps) at 240V
40
Recommended Circuit Breaker (Amps) at 240V
- 40
Max. Connected Load (kW) at 240V
9.3
Max. Connected Load (kW) at 240V
- 9.3
Max. Current Draw (Amps) at 240V
38.8
Max. Current Draw (Amps) at 240V
- 38.8
Max. Connected Load (kW) at 208V
7.0
Max. Connected Load (kW) at 208V
- 7.0
Recommended Circuit Breaker (Amps) at 208V
40
Recommended Circuit Breaker (Amps) at 208V
- 40
Max. Current Draw (Amps) at 208V
33.6
Max. Current Draw (Amps) at 208V
- 33.6
WARRANTY
Parts Warranty
Limited 1-year entire appliance
Parts Warranty
- Limited 1-year entire appliance
Warranty Notes
See written warranty for full details
Warranty Notes
- See written warranty for full details
Labor Warranty
Limited 1-year entire appliance
Labor Warranty
- Limited 1-year entire appliance
WEIGHTS & DIMENSIONS
Cooktop Size
36 in
Cooktop Size
- 36 in
Overall Height
5.5625 in
Overall Height
- 5.5625 in
Cutout Depth (in)
19-1/8
Cutout Depth (in)
- 19-1/8
Cabinet Width
36 in
Cabinet Width
- 36 in
Approximate Shipping Weight
57 lb
Approximate Shipping Weight
- 57 lb
Overall Width
36 in
Overall Width
- 36 in
Net Weight
46 lb
Net Weight
- 46 lb
Cutout Width (in)
33-7/8
Cutout Width (in)
- 33-7/8
Overall Depth
20.375 in
Overall Depth
- 20.375 in
FEATURES
Cooktop Burner Type
5 Ribbon
Smoothtop
Cooktop Burner Type
- 5 Ribbon Smoothtop
Melt Setting
Yes
Melt Setting
- Yes
Fuel Type
Electric
Fuel Type
- Electric
Element - Left Front
7" 1500W
Element - Left Front
- 7" 1500W
Indicator Lights
5 Hot Surface
Red
Setting Level Indicators
Surface Element "ON"
Indicator Lights
- 5 Hot Surface Red Setting Level Indicators Surface Element "ON"
Element - Right Front
8"/5" 2400W Power Boil
Element - Right Front
- 8"/5" 2400W Power Boil
Control Location
Front Center
Control Location
- Front Center
Cooktop Type
Radiant Smoothtop
Cooktop Type
- Radiant Smoothtop
Cooktop Surface
Black Ceramic Glass
Cooktop Surface
- Black Ceramic Glass
Cooktop Control Features
All-Off Control
Control Lock Capability
Keep-Warm Setting
Kitchen timer
Melt Setting
Cooktop Control Features
- All-Off Control Control Lock Capability Keep-Warm Setting Kitchen timer Melt Setting
Timer
Yes
Timer
- Yes
Element - Left Rear
6" 1200W
Element - Left Rear
- 6" 1200W
Control Type
Electronic Touch
Control Type
- Electronic Touch
Element - Center
12"/9"/6" 3000W Tri-ring
Element - Center
- 12"/9"/6" 3000W Tri-ring
Element - Right Rear
6" 1200W
Element - Right Rear
- 6" 1200W
Features
Power Boil Dual-Ring Element, Control lock capability, Digital Touch Controls, Red LED with Black Glass Surface, Hot surface indicator lights, Power Boil Tri-Ring Element, Kitchen timer, Five radiant cooking elements, Keep Warm Setting, Melt Setting
- Power Boil Dual-Ring Element
- Control lock capability
- Digital Touch Controls
- Red LED with Black Glass Surface
- Hot surface indicator lights
- Power Boil Tri-Ring Element
- Kitchen timer
- Five radiant cooking elements
- Keep Warm Setting
- Melt Setting
Item & Dimensions
Manufacturer
GE Appliances
Manufacturer
- GE Appliances
The Electric Ranges Ge® 36" Built-In Touch Control Electric Cooktop, made by GE Appliances,
is brought to you by Simon's Furniture. Simon's Furniture is a local furniture store, serving the Boston, Franklin, Wrentham, Norfolk, Attleboro, Bellingham, Foxboro, Holliston, Hopkinton, Medfield, Medway, Milford, Millis, Plainville, Walpole Massachusetts and Providence, Rhode Island area. Product availability may vary.
Contact us for the most current availability on this product.
Collection Details
The Electric Ranges collection is an amazing option if you are looking for
Appliances.
Our store serves the Boston, Franklin, Wrentham, Norfolk, Attleboro, Bellingham, Foxboro, Holliston, Hopkinton, Medfield, Medway, Milford, Millis, Plainville, Walpole Massachusetts and Providence, Rhode Island area.
Similar search terms: Cooktops, Electric Cooktop, Gas Cooktop, Down Draft Cooktop, Cook Top, Cooktop Range, Ranges, Cooktop with Downdraft, Kitchen Cooktop, Kitchen Appliances, Appliances, Stove, Kitchen Stove, Cook Top Stove, Cooker, Cookstove, Cook Stove, Stove Top, Rangetops, Range Top
Reference #: JP5036DJBB
