800 Series Dishwasher 24" Black Stainless Steel

SKU: SHPM78Z54N
Discontinued - Contact Us For A Replacement Model

Where Can I See This Product in Store?

more
This product is not on display in our showrooms.
Estimated Delivery Price
Enter your zip code to get a delivery estimate.

Ask a Question

less
First Name is required
Last Name is required
Email Address is required
Message is required

Dimensions:

23.56" W × 23.75" D × 33.87" H
remove add
Width (side to side) 23.56
Depth (front to back) 23.75
Height (bottom to top) 33.87

Disclaimer

remove add

Description

more
BOSCH SHPM78Z54N 800 Series Dishwasher
  • Know when your dishwasher is running with InfoLight®
  • 42 dBA -- the quietest dishwasher brand in the U.S.*
  • Newly redesigned EasyGlide™ rack system for a smooth glide on all three racks.
  • Fit in tall items with RackMatic®
  • A smarter clean with PrecisionWash®
  • Create room for bulky items with FlexSpace™ Tines
  • A Standard Silverware Basket to store utensils on the bottom rack
  • Prevent leaks with AquaStop®
  • 24h Delay Start Timer for a later start time
  • The ultimate dry with CrystalDry™

Rebates

view available rebates
800 Series Dishwasher 24" Black Stainless Steel
800 Series Dishwasher 24" Black Stainless Steel
Dishwashers Collection

Specifications

Specifications

remove add

Product

Tall Tub Design Yes
Tall Tub Design
  • Yes
Sabbath Mode No
Sabbath Mode
  • No
Wifi Enabled No
Wifi Enabled
  • No
Dishwasher Sound Rating Quiet (40-49dB)
Dishwasher Sound Rating
  • Quiet (40-49dB)
Install Type Built-In
Install Type
  • Built-In
Energy Star Compliant Yes
Energy Star Compliant
  • Yes

Dimensions

Height (bottom to top) 33.87" H
Height (bottom to top)
  • 33.87" H
Width (side to side) 23.56" W
Width (side to side)
  • 23.56" W
Depth (front to back) 23.75" D
Depth (front to back)
  • 23.75" D

Features & Function

Tub Material Stainless Steel
Tub Material
  • Stainless Steel
Maximum Spin Speed (RPM) -1.0
Maximum Spin Speed (RPM)
  • -1.0
Control Location Top
Control Location
  • Top
Decibel Sound Rating 42.0
Decibel Sound Rating
  • 42.0

Style Elements

Color Family Black Stainless Steel
Color Family
  • Black Stainless Steel
Color Name Black Stainless Steel
Color Name
  • Black Stainless Steel

General

Appliance Width (in) 23 9/16
Appliance Width (in)
  • 23 9/16
Height 33 7/8
Height
  • 33 7/8
Installation Type Built-under
Installation Type
  • Built-under
Number of Place Settings 16
Number of Place Settings
  • 16
List of Programs Auto, Glass, Heavy, Normal, Rinse, Speed 60
List of Programs
  • Auto, Glass, Heavy, Normal, Rinse, Speed 60
Cycle Options Crystal Dry, Delicate, Half Load, Sanitize
Cycle Options
  • Crystal Dry, Delicate, Half Load, Sanitize
Display Yes
Display
  • Yes
Silence Level 42 dB(A) re 1 pW
Silence Level
  • 42 dB(A) re 1 pW
3rd rack Flexible 3rd rack
3rd rack
  • Flexible 3rd rack
Interior Light No
Interior Light
  • No
Removable top No
Removable top
  • No
Power Cord Length 67''
Power Cord Length
  • 67''

Connectivity

Home Connect(TM) No
Home Connect(TM)
  • No

Size and weight

Overall Appliance Dimensions (HxWxD) (in) 33 7/8'' x 23 9/16'' x 23 3/4''
Overall Appliance Dimensions (HxWxD) (in)
  • 33 7/8'' x 23 9/16'' x 23 3/4''
Adjustable plinth No
Adjustable plinth
  • No
Net Weight 96.000 lbs
Net Weight
  • 96.000 lbs

Programmes

Status indicator End of program audible, InfoLight red, Sanitized LED US, Time remaining indic. internal
Status indicator
  • End of program audible, InfoLight red, Sanitized LED US, Time remaining indic. internal
List of Programs Auto, Glass, Heavy, Normal, Rinse, Speed 60
List of Programs
  • Auto, Glass, Heavy, Normal, Rinse, Speed 60
Program 1 Heavy
Program 1
  • Heavy
Program 2 Auto
Program 2
  • Auto
Program 3 Glass
Program 3
  • Glass
Program 4 Normal
Program 4
  • Normal
Program 5 Speed 60
Program 5
  • Speed 60
Program 6 Rinse
Program 6
  • Rinse
Programme duration, programme1 (min.) 110-135
Programme duration, programme1 (min.)
  • 110-135
Programme duration, programme2 (min.) 105-129
Programme duration, programme2 (min.)
  • 105-129
Programme duration, programme3 (min.) 75-85
Programme duration, programme3 (min.)
  • 75-85
Programme duration, programme4 (min.) 130-135
Programme duration, programme4 (min.)
  • 130-135
Programme duration, programme5 (min.) 65
Programme duration, programme5 (min.)
  • 65
Programme duration, programme6 (min.) 9
Programme duration, programme6 (min.)
  • 9
Reference program Eco
Reference program
  • Eco
Temperature program 1 151-160 °F
Temperature program 1
  • 151-160 °F
Temperature program 2 127-140 °F
Temperature program 2
  • 127-140 °F
Temperature program 3 113-122 °F
Temperature program 3
  • 113-122 °F
Temperature program 4 113-131 °F
Temperature program 4
  • 113-131 °F
Temperature program 5 122 °F
Temperature program 5
  • 122 °F

Safety

ChildLock No
ChildLock
  • No

Consumption values

Glass protection No
Glass protection
  • No
Water consumption program 1 4.9-6.4 gal
Water consumption program 1
  • 4.9-6.4 gal
Water consumption program 2 3.4-6.4 gal
Water consumption program 2
  • 3.4-6.4 gal
Water consumption program 3 2.4-3.9 gal
Water consumption program 3
  • 2.4-3.9 gal
Water consumption program 4 2.4-5.5 gal
Water consumption program 4
  • 2.4-5.5 gal
Water consumption program 5 3.8 gal
Water consumption program 5
  • 3.8 gal
Water consumption program 6 1.1 gal
Water consumption program 6
  • 1.1 gal
Total Annual Water Consumption 624 gal
Total Annual Water Consumption
  • 624 gal
Maximum temperature for water intake ((degree)C) 60 °C
Maximum temperature for water intake ((degree)C)
  • 60 °C

Connection

Watts 1,440 W
Watts
  • 1,440 W
Power Cord Length 67''
Power Cord Length
  • 67''
Fuse protection 12 A
Fuse protection
  • 12 A
Plug type Nema5-15P
Plug type
  • Nema5-15P

Construction type

Color / Material housing Lacquered
Color / Material housing
  • Lacquered
Color / Control Panel Black
Color / Control Panel
  • Black
Construction Type Built-in
Construction Type
  • Built-in
Drying System Inherent heat, Zeolite
Drying System
  • Inherent heat, Zeolite
Height 33 7/8
Height
  • 33 7/8
Concealed heating element Yes
Concealed heating element
  • Yes
Installation Type Built-under
Installation Type
  • Built-under
Tub material Stainless steel
Tub material
  • Stainless steel
Water Softener No
Water Softener
  • No
Appliance Width (in) 23 9/16
Appliance Width (in)
  • 23 9/16

Features

Know when your dishwasher is running with InfoLight®, 42 dBA -- the quietest dishwasher brand in the U.S.*, Newly redesigned EasyGlide™ rack system for a smooth glide on all three racks., Fit in tall items with RackMatic®, A smarter clean with PrecisionWash®, Create room for bulky items with FlexSpace™ Tines, A Standard Silverware Basket to store utensils on the bottom rack, Prevent leaks with AquaStop®, 24h Delay Start Timer for a later start time, The ultimate dry with CrystalDry™
  • Know when your dishwasher is running with InfoLight®
  • 42 dBA -- the quietest dishwasher brand in the U.S.*
  • Newly redesigned EasyGlide™ rack system for a smooth glide on all three racks.
  • Fit in tall items with RackMatic®
  • A smarter clean with PrecisionWash®
  • Create room for bulky items with FlexSpace™ Tines
  • A Standard Silverware Basket to store utensils on the bottom rack
  • Prevent leaks with AquaStop®
  • 24h Delay Start Timer for a later start time
  • The ultimate dry with CrystalDry™

Item & Dimensions

Manufacturer Bosch
Manufacturer
  • Bosch
The Dishwashers 800 Series Dishwasher 24" Black Stainless Steel, made by Bosch, is brought to you by Simon's Furniture. Simon's Furniture is a local furniture store, serving the Boston, Franklin, Wrentham, Norfolk, Attleboro, Bellingham, Foxboro, Holliston, Hopkinton, Medfield, Medway, Milford, Millis, Plainville, Walpole Massachusetts and Providence, Rhode Island area. Product availability may vary. Contact us for the most current availability on this product.

Collection Details

The Dishwashers collection is an amazing option if you are looking for Appliances. Our store serves the Boston, Franklin, Wrentham, Norfolk, Attleboro, Bellingham, Foxboro, Holliston, Hopkinton, Medfield, Medway, Milford, Millis, Plainville, Walpole Massachusetts and Providence, Rhode Island area.
Similar search terms: Dishwasher, Portable Dishwasher, Built In Dishwasher, Dish Drawer, Compact Dishwasher, Large Dishwasher, Kitchen Appliances
Reference #: SHPM78Z54N
