115V 12,000 Btu Side Discharge Air Conditioner Condensing Unit

Air Conditioners Collection by GE Appliances
SKU: UUC112WCDA
Be the first to write a review

Where Can I See This Product in Store?

This product is not on display in our showrooms.
Estimated Delivery Price
Enter your zip code to get a delivery estimate.

Ask a Question

First Name is required
Last Name is required
Email Address is required
Message is required

Description

Compact Size
Side-discharge configuration is perfect for installation in limited space

Light Weight
Easier contractor equipment transportation and installation

Quiet Operation
Sound-dampening features produce operation at noise levels as low as 52dB

24V System
Compatible with many 24VAC thermostat

AHRI Matching Indoor Coil
Independent 3rd party coil match available

See specification book for full heating, cooling, and system details
  • 24V System
  • Light Weight
  • Quiet Operation
  • AHRI Matching Indoor Coil
  • Compact Size
  • See specification book for full heating, cooling, and system details
Installation Instructions
Installation Instructions
View PDF for more information
Literature
Literature
View PDF for more information

Rebates

view available rebates
115V 12,000 Btu Side Discharge Air Conditioner Condensing Unit
115V 12,000 Btu Side Discharge Air Conditioner Condensing Unit
Air Conditioners Collection

Specifications

Specifications

remove

Product

Appliance Color White
Appliance Color
  • White

Dimensions

Height (bottom to top) 22.0" H
Height (bottom to top)
  • 22.0" H
Width (side to side) 33.5" W
Width (side to side)
  • 33.5" W
Depth (front to back) 13.625" D
Depth (front to back)
  • 13.625" D

Style Elements

Color Family White / Cream
Color Family
  • White / Cream
Color Name White
Color Name
  • White

Features

24V System, Light Weight, Quiet Operation, AHRI Matching Indoor Coil, Compact Size, See specification book for full heating, cooling, and system details
  • 24V System
  • Light Weight
  • Quiet Operation
  • AHRI Matching Indoor Coil
  • Compact Size
  • See specification book for full heating, cooling, and system details

CAPACITY

Cooling BTUH (MAX) 12000 Btu
Cooling BTUH (MAX)
  • 12000 Btu

APPEARANCE

Color Appearance White
Color Appearance
  • White

POWER / RATINGS

Cooling Rated Capacity BTU/Hr 12,000
Cooling Rated Capacity BTU/Hr
  • 12,000
Minimum Circuit Amp 11
Minimum Circuit Amp
  • 11

WARRANTY

Parts Warranty 10-Year Limited Parts and Compressor Warranty with Registration Limited 5-Year Parts and Compressor
Parts Warranty
  • 10-Year Limited Parts and Compressor Warranty with Registration Limited 5-Year Parts and Compressor

WEIGHTS & DIMENSIONS

Net Weight 76.1 lb
Net Weight
  • 76.1 lb
Suction O.D. Refrigerant Line 1/2"
Suction O.D. Refrigerant Line
  • 1/2"
Liquid O.D. Refrigerant Line 1/4"
Liquid O.D. Refrigerant Line
  • 1/4"
Overall Depth 13.625 in
Overall Depth
  • 13.625 in
Factory Charge (pounds) 4.1999998092651 lb
Factory Charge (pounds)
  • 4.1999998092651 lb
Overall Width 33.5 in
Overall Width
  • 33.5 in
Overall Height 22 in
Overall Height
  • 22 in
Approximate Shipping Weight 92.6 lb
Approximate Shipping Weight
  • 92.6 lb

FEATURES

Style Side-Discharge
Style
  • Side-Discharge
Refrigerant Type R410A
Refrigerant Type
  • R410A
Maximum Line Length (Ft/M) 82/25
Maximum Line Length (Ft/M)
  • 82/25
Series Side-Discharge
Series
  • Side-Discharge
Maximum Height (Ft/m) 33/10
Maximum Height (Ft/m)
  • 33/10
Temperature Range - Cooling Mode 50-115 F (10-46 C)
Temperature Range - Cooling Mode
  • 50-115 F (10-46 C)
Unit Type Indoor
Unit Type
  • Indoor
SEER 14
SEER
  • 14
Compressor Type Rotary
Compressor Type
  • Rotary
Maximum Fuse Size A 15
Maximum Fuse Size A
  • 15
EER 12
EER
  • 12
Fan Speed RPM 820
Fan Speed RPM
  • 820
Outdoor Noise Level 52 dBA
Outdoor Noise Level
  • 52 dBA
Outdoor Airflow CFM 1220
Outdoor Airflow CFM
  • 1220
CFM with Rated Coils 445
CFM with Rated Coils
  • 445
Aspen Model C(A,C,E)24A24+TDR
Aspen Model
  • C(A,C,E)24A24+TDR
Product Type Multi Zone Single Zone
Product Type
  • Multi Zone Single Zone

Item & Dimensions

Manufacturer GE Appliances
Manufacturer
  • GE Appliances
The Air Conditioners 115V 12,000 Btu Side Discharge Air Conditioner Condensing Unit, made by GE Appliances, is brought to you by Simon's Furniture. Simon's Furniture is a local furniture store, serving the Boston, Franklin, Wrentham, Norfolk, Attleboro, Bellingham, Foxboro, Holliston, Hopkinton, Medfield, Medway, Milford, Millis, Plainville, Walpole Massachusetts and Providence, Rhode Island area. Product availability may vary. Contact us for the most current availability on this product.
